, AC 65 Series

Applications: heating units, cooling systems, electric fireplace, air curtain, etc
Turbine diameter: 65mm,
Turbine length: 180mm, 240mm, 300mm, 360mm
Insulation level: B, F, H
Exported to: United States, Canada, Poland, Germany, etc
MOQ: 5000PCS/PO

Parameters
Model Voltage (V) Frequency (Hz) Maximum Input Power (W) Maximum Discharge (m ³/h) Rotating Speed (RPM) Noise (dB)
PLD6120-GL65120 230 50 15 85 1300 42
PLD6125-GL65180 231 50 30 170 1500 46
PLD6130-GL65240 232 50 38 220 1200 42
PLD6135-GL65360 233 50 42 250 1200 42
