This product has been discontinued and removed from our shelves.

Application

Wall mounted fan coil units are widely used as air conditioner combinations in multiple rooms or large spaces in industrial and civil buildings, such as hotels, restaurants, factories, hospitals, galleries, malls, and office buildings in order to meet building cooling, heating and ventilation requirements.

Parameters

Model		FP-35BG	FP-68BG	FP-84BG	FP-102BG
P		1 P	1.5P	2P	3P
Air flow(m3/h)	H	340	680	840	1020
	M	300	480	685	780
	L	230	360	580	650
Cooling capacity(W)	H	1980	3500	4500	5400
	M	1630	2610	3440	4500
	L	1380	2150	2750	3800
Heating capacity(W)	H	2970	5250	6750	8100
	M	2450	3950	5160	6800
	L	2060	3700	4130	6000
Noise dB（A）		≤36	≤45	≤48	≤48
Cooling water temperature		7℃-12℃
Heating water temperature		60℃-50℃
Power（V/Hz）		Single-phase AC 220V、50Hz
Water inlet and outlet		ZG1/2
Dimension（L×W×H）		890×290×180	890×120×180	1030×290×185	1080×330×215
Unit weight（kg）		9	12.8	14	16

Model (2 pipes)				RFP034W	RFP051W	RFP068W	RFP085W	RFP102W	RFP136W
Power				220V, 50Hz, 1Ph
Nominal air flow		H	m3/h	340	510	680	850	1020	1360
		M		280	380	515	660	765	1010
		L		180	260	340	430	530	710
Static pressure			Pa	0	0	0	0	0	0
Cooling capacity	TH	H	W	1800	2700	3600	4500	5400	7200
	TH		BTU/h	6142	9212	12283	15354	18425	24566
	SH		W	1350	2025	2700	3375	4050	5400
	SH		BTU/h	4606	6909	9212	11516	13819	18424
	TH	M	W	1476	2214	2952	3690	4428	5904
	TH	M	W	978	1399	1963	2409	3044	3926
	SH	L	W	1098	1647	2196	2745	3294	4392
	SH	L	W	649	960	1355	1715	2060	2710
Heating capacity	H		W	2700	4050	5400	6750	8100	10800
	M		W	2146	3219	4293	5366	6439	8586
	L		W	1512	2268	3024	3780	4536	6048
Noise	H	0Pa	dB(A)	37	39	41	43	45	46
Input power	H	0Pa	W	30	38	45	50	90	100
Water flow			m3/h	0.31	0.46	0.62	0.77	0.93	0.93
Water resistance			kPa	12	14	17	18	22.5	23.5
Dimension of joint pipe for water inflow and outflow			Water inflow	ZG1/2"	ZG1/2"	ZG1/2"	ZG1/2"	ZG1/2"	ZG1/2"
Dimension of joint pipe for water inflow and outflow			Water outflow	ZG1/2"	ZG1/2"	ZG1/2"	ZG1/2"	ZG1/2"	ZG1/2"
Coil			Type	high efficient copper tube with aluminum outer ring (with hydrophilic aluminum surface)
Max. pressure			MPa	1.6	1.6	1.6	1.6	1.6	1.6
Dimension of condensate water joint pipe			mm	￠16	￠16	￠16	￠16	￠16	￠16
Unit dimension	L×W×H		mm	795285215	795285215	990＊330＊230	990＊330＊230	1090＊330＊255	1090＊330＊255
Package size	L×W×H		mm	905370283	905370283	1065375275	1065375275	1145375315	1145375315
Weight			kg	11.2	11.2	14.5	14.5	16.5	16.5

Features of wall mounted fan coil unit

Easy control: use of micro-computerized controller, infrared wireless remote control with time switch, temperature setting, three-speed (H-M-L) automatic control, air direction automatic changing and a room temperature display bring convenience and excellence for wall mounted fan coil unit.
Reliability and safety. Coils all pass pressure & leak testing. Joint pipes in the inlet and outlet (collecting head) use brass to be both reliable and durable with a service life of more than 45,000 hours.
High efficiency and sufficient capacity: The heat exchanger uses a seamless copper tube and it expands into one with aluminum vanes, with the advantages of a high heat exchanging efficiency and sufficient cooling and heating capacity.
Low noise: This fan coil unit uses oil-free rolling bearings with a new type of cross flow vane.
Long service life: An aluminum alloy wind wheel guarantees the wind wheel is invulnerable to deformation, saving the effort of needing to be heated in winter, thus extending the service life.
