Material Discharge Hose
Request a Quote
Basic Information
- Inner tube: Natural Butyl rubber compound (Tensile strength ≥17MPa)
- Inner tube abrasion coefficient: ≤0.06
- Reinforcement: Textile cord braided
- Outer cover: Natural Butyl rubber compound (Tensile strength ≥9MPa)
- Working temperature: -20°C to 80°C
- Safety factor: 3:1
- Color: Available in black, green, and other colors
- The inner tube exhibits excellent abrasion resistance.
- The outer cover provides high strength, ensuring reliable performance under various working conditions.
The material conveying hose finds extensive use in industries such as mining, metallurgy, chemical, and construction materials. It is primarily employed for transporting materials like coal, iron ore, steel, cement, sand, and gravel, serving as a durable alternative to traditional metal or glass pipelines. Its superior resistance to wear and corrosion, coupled with its high durability and reduced risk of rupture, contribute to enhanced production efficiency, equipment stability, and cost-effectiveness.
Technical Parameters
Item Code | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Inner Rubber Thickness | Weight | Max. Length | |||
mm | inch | mm | bar | psi | bar | psi | mm | kg/m | m | |
BMD025-150 | 25 | 1" | 38.8 | 10 | 150 | 30 | 300 | 3 | 2.85 | 61 |
BMD032-150 | 32 | 1-1/4" | 45.8 | 10 | 150 | 30 | 300 | 3 | 2.85 | 61 |
BMD038-150 | 38 | 1-1/2" | 54.4 | 10 | 150 | 30 | 300 | 4 | 3.8 | 61 |
BMD051-150 | 51 | 2" | 67.4 | 10 | 150 | 30 | 300 | 4 | 3.8 | 61 |
BMD064-150 | 64 | 2-1/2" | 81.4 | 10 | 150 | 30 | 300 | 4 | 3.8 | 61 |
BMD076-150 | 76 | 3" | 95.8 | 10 | 150 | 30 | 300 | 5 | 4.75 | 61 |
BMD089-150 | 89 | 3-1/2" | 111.2 | 10 | 150 | 30 | 300 | 5 | 4.75 | 61 |
BMD102-150 | 102 | 4" | 124.2 | 10 | 150 | 30 | 300 | 5 | 4.75 | 61 |
BMD127-150 | 127 | 5" | 151.2 | 10 | 150 | 30 | 300 | 5 | 4.75 | 61 |
BMD152-150 | 152 | 6" | 178.6 | 10 | 150 | 30 | 300 | 6 | 5.7 | 61 |
BMD025-300 | 25 | 1" | 36.8 | 20 | 300 | 60 | 900 | 3 | 0.71 | 61 |
BMD032-300 | 32 | 1-1/4" | 45.8 | 20 | 300 | 60 | 900 | 3 | 1.12 | 61 |
BMD038-300 | 38 | 1-1/2" | 53.8 | 20 | 300 | 60 | 900 | 4 | 1.50 | 61 |
BMD051-300 | 51 | 2" | 66.8 | 20 | 300 | 60 | 900 | 4 | 1.93 | 61 |
BMD064-300 | 64 | 2-1/2" | 80.6 | 20 | 300 | 60 | 900 | 4 | 2.35 | 61 |
BMD076-300 | 76 | 3" | 97.4 | 20 | 300 | 60 | 900 | 5 | 3.64 | 61 |
BMD089-300 | 89 | 3-1/2" | 110.4 | 20 | 300 | 60 | 900 | 5 | 4.18 | 61 |
BMD102-300 | 102 | 4" | 123.4 | 20 | 300 | 60 | 900 | 5 | 4.72 | 61 |
BMD127-300 | 127 | 5" | 149.6 | 20 | 300 | 60 | 900 | 5 | 6.26 | 61 |
BMD152-300 | 152 | 6" | 176.6 | 20 | 300 | 60 | 900 | 6 | 8.08 | 61 |
Note: Specifications, pressures, colors, Inner rubber thickness, etc. can be customized according to requirements.
