Bulk Material Handling Discharge Hose Type:BM10/BM20 Manufacturer

Bulk Material Handling Discharge Hose Type:BM10/BM20

Request a Quote

View All: http://tech-flexcn.com/1-5-2-1-bulk-material-handling-discharge-hose.html

Application:

Bulk material handling discharge hoses are widely used to transport dry cement and other grinding materials. The wear and tear level of the inner tube meets ISO4649 standards at ≤ 60mm³.

Temperature Range:

-35℃ ~ 75℃

Construction:

Tube: Black composite thickened rubber with an excellent abrasion and static resistance
Reinforcement: High strength synthetic fiber cord or steel cord
Cover: Black composite rubber in cloth texture, abrasion and aging resistance

BM10 Series Technical Parameters:

Code No.	Size (inch)	I.D. (mm)	O.D. (mm)	W.P. (bar) (psi)		B.P. (bar) (psi)		Safety Factor	MBR (mm)	Weight (Kg/m)	Max. Length (m)
BM10-51	2"	51		10	150	30	450	3			100
BM10-64	2-1/2"	64		10	150	30	450	3			100
BM10-76	3"	76		10	150	30	450	3			100
BM10-89	3-1/2"	89		10	150	30	450	3			61
BM10-102	4"	102		10	150	30	450	3			61
BM10-127	5"	127		10	150	30	450	3			61
BM10-152	6"	152		10	150	30	450	3			61
BM10-203	8"	203		10	150	30	450	3			61

BM20 Technical Parameters:

Code No.	Size (inch)	I.D. (mm)	O.D. (mm)	W. P. (bar) (psi)		B. P. (bar) (psi)		Safety Factor	MBR (mm)	Weight(Kg/m)	Max. Length (m)
BMH20-51	2"	51		20	300	60	900	3			100
BMH20-64	2-1/2"	64		20	300	60	900	3			100
BMH20-76	3"	76		20	300	60	900	3			100
BMH20-89	3-1/2"	89		20	300	60	900	3			61
BMH20-102	4"	102		20	300	60	900	3			61
BMH20-127	5"	127		20	300	60	900	3			61
BMH20-152	6"	152		20	300	60	900	3			61
BMH20-203	8"	203		20	300	60	900	3			61
