Side Sealing & Cutting Bag Making Machine, DRQ (OPP Bag Machine)

Side Sealing & Cutting Bag Making Machine, DRQ (OPP Bag Machine)
Side Sealing & Cutting Bag Making Machine, DRQ (OPP Bag Machine)
Side Sealing & Cutting Bag Making Machine, DRQ (OPP Bag Machine)
Request a Quote

This side sealing bag making machine is suitable for heat cutting and side sealing printed or without printed plastic film (OPP, PP, PE, PET), it is a kind of ideal equipment for making garment bag, towel bag, bread bag and cosmetic bag, etc.

Features
  • The whole machine adopts microcomputer control and material pulling by step motor (option: Servo motor control system)
  • With the functions: length positioning, photocell tracking, automatic stop when lose tracking mark.
  • Add double side adhesive tape in same process, automatic pneumatic punching (ф6~8mm).
  • Heat dot sealing, automatic constant control temperature, with firm and smooth sealing.
Specification
Model
DRQ500
DRQ600
DRQ700
DRQ800
DRQ1000
Bag length 50~700mm 50~700mm 50~700mm 50~700mm 50~700mm
Max width 500mm 600mm 700mm 800mm 1000mm
Speed 60~200pcs/min depend on bag making size and material
Total power 3.5kw 4kw 5kw 5.5kw 6kw
Dimension 3.7x1.2x1.2m 3.7x1.3x1.2m 3.7x1.4x1.2m 3.7x1.5x1.2m 3.7x1.7x1.2m
Weight 800kg 850kg 900kg 950kg 1000kg
