Unleash the Depths with Our Double Casing Drilling System

Our high-quality casing pipes are a vital component of our comprehensive drilling solutions. Designed to support and protect drill bits, these pipes play a crucial role in achieving the desired hole diameter while stabilizing drilling operations to prevent deviation. With customizable options available, our casing pipes are tailored to meet your unique drilling needs.

Specifications
Outer diameter (mm) Reamed diameter (mm) Inner diameter (mm) Thread diameter (mm) Drill pipe diameter (mm) Drill bit diameter Thread
118 125 88 104.5 76 83 R56
133 140 108 122 76 102 R56
146 152 120 134 89 116 R78
168 172 133 146.5 114 128 R83
216 225 178 203 114 165 R102
Features
  • Through advanced surface hardening techniques, we fortify our drilling tools to withstand high pressures and resist wear.
  • Our tools boast an optimized internal structure, resulting in smoother and more efficient drilling processes.
  • Our double casing drilling system is designed to reduce procurement costs while enhancing production efficiency.
  • From easy rod connections to intuitive controls, our tools make drilling operations seamless and hassle-free.
