CNC Router with Vacuum Table
Request a Quote

This CNC router is designed with a vacuum table that adopts world's advanced vacuum system. The vacuum pump offers strong absorption force to absorb materials of different sizes firmly. T slots are also supplied for mechanical clamping, so that operator can use either vacuum clamping or T-slot clamping according to the actual needs.

Applications

This CNC router is widely used for producing advertising signs, acrylic letters, wood doors, etc. It is applicable to a number of materials, such as steel, brass, aluminum, plastic, acrylic, wood, and other metal or non-metal materials.

Specifications
Model RJ1212C RJ1325C RJ1530C RJ2030C RJ2040C
Working area (mm) 1200x1200mm 1300x2500mm 1500x3000mm 2000x3000mm 2000x4000mm
Z-axis travel height 180mm/230mm/330mm
Max. engraving speed 20000mm/min
Working accuracy ±0.08/300mm
Spindle power 3KW/5.5KW/6KW/7.5KW/9KW
Spindle speed 6000—24000rpm
Tool diameter Ø3.175mm, Ø6mm, Ø12.7mm
X/Y/Z guide rails Linear guide rails
Transmission X/Y axis rack and pinion, Z axis ball screw
Voltage AC380V/50HZ
Command code HPGL,G Code
Dust collector 3kW
Vacuum power 5.5kW/7.5kW
Features
  • DSP control system

    DSP hand controller makes operation easier and more simple. It uses handle to manually control the motion of CNC router, eliminating the need for an additional computer thereby decreasing the required footprint.

  • Linear guide rail

    Square linear guides from world's renowned brand are used to ensure high precision, large loading capacity and long service life.

  • Powerful spindle

    High power brushless water-cooled spindle ensures reliable operation with less noise, allowing operator to perform batch processing for a long time.

  • Rack and pinion transmission

    The rack and pinion transmission guarantees high speed and high precision.

  • Richauto DSP

    DSP control plays a vital role in the operation of CNC router. Richauto DSP control can achieve fast computing speed and strong processing capacity.
    16-key keyboard, simple to use;
    Multi-language display, easy to change languages;

  • T-slot and vacuum table

    The vacuum bed is built using world's advanced technology and configured with powerful vacuum pump, stably accommodating various workpieces of different sizes.
