HSS End Mill-3 Flute
Request a Quote
Application
3 flute milling tools are often used to mill materials with a tensile strength lower than 1300N /mm², and are often used for milling of flat surfaces, side surfaces, groove shaping, and workpiece cutting.
Function
milling and cutting
Material
high speed steel (HSS)
Parameters
| Cutter Diameter mm (A) | Shank Diameter mm (B) | Flute Length mm (C) | Overall Length mm (D) | Flute Quantity (E) |
| 3 | 6 | 11 | 60 | 3 |
| 4 | 6 | 12 | 60 | 3 |
| 5 | 6 | 15 | 60 | 3 |
| 6 | 6 | 19 | 63 | 3 |
| 8 | 8 | 22 | 66 | 3 |
| 10 | 10 | 25 | 75 | 3 |
| 12 | 12 | 35 | 85 | 3 |
| 14 | 12 | 35 | 90 | 3 |
| 16 | 16 | 40 | 95 | 3 |
| 18 | 16 | 42 | 95 | 3 |
| 20 | 20 | 50 | 110 | 3 |
