HSS End Mill-4 Flute
Request a Quote
Application
This 4-flute milling tool is primarily used in milling machines to cut workpieces and shape flat surface, side surfaces, and grooves.
Function
milling and cutting
Material
high speed steel (HSS)
Parameters
| Cutter Diameter mm (A) | Shank Diameter mm (B) | Flute Length mm (C) | Overall Length mm (D) | Flute Quantity (E) |
| 1 | 6 | 4 | 60 | 4 |
| 2 | 6 | 11 | 60 | 4 |
| 3 | 6 | 11 | 60 | 4 |
| 4 | 6 | 12 | 60 | 4 |
| 5 | 6 | 15 | 60 | 4 |
| 6 | 6 | 19 | 63 | 4 |
| 7 | 8 | 25 | 66 | 4 |
| 8 | 8 | 25 | 66 | 4 |
| 9 | 10 | 25 | 75 | 4 |
| 10 | 10 | 25 | 75 | 4 |
| 11 | 12 | 35 | 85 | 4 |
| 12 | 12 | 35 | 85 | 4 |
| 13 | 12 | 35 | 85 | 4 |
| 14 | 12 | 35 | 90 | 4 |
| 15 | 16 | 42 | 95 | 4 |
| 16 | 16 | 42 | 95 | 4 |
| 17 | 16 | 42 | 95 | 4 |
| 18 | 16 | 42 | 95 | 4 |
| 19 | 20 | 50 | 110 | 4 |
| 20 | 20 | 50 | 110 | 4 |
| 22 | 20 | 50 | 110 | 4 |
| 25 | 25 | 50 | 125 | 4 |
