COMPACT CJ Laser Welding Machine
Laser welding system with enclosed chamber
The COMPACT CJ laser welding machine offers streamlined solutions for welding round or circumferential parts, adept at handling complex joint geometries across small to medium sizes. This model features a mobile dual-station mode for enhanced configurability and supports a one-to-many multi-workstation mode, boosting production efficiency significantly. Designed with professional users in mind, the COMPACT CJ combines high efficiency and flexibility, delivering a dependable solution for circular welding tasks.
- Laser power500-5,000W
- Axis travel X＝400mm, Y＝300mm, Z=250mm
- Parts Filter, gear, sensor, flywheel, injection valve, high pressure pump, etc.
As a leader in the Chinese laser industry, PENTA LASER specializes in the design and manufacture of high performance laser machines for a wide range of industries, including automotive, shipbuilding, agricultural machinery. Contact with us for a full custom laser engineering solution.
- Auto Parts
- Shipbuilding
- Oil Equipment
- Railcar
- Enclosure
- Agricultural Machinery
- Kitchenware & Kitchen Appliances
| Axis | |
| Y axis travel | 350mm |
| Z axis travel | 300mm |
| P axis travel | 0-90° |
| B1 axis travel | N*360° |
| B2 axis travel | N*360° |
| Accuracy | |
| Positioning accuracy of X,Y and Z axes | ±0.05mm/m |
| Repetitive positioning accuracy of Y and Z axes | ±0.03mm |
| Positioning accuracy of P reducer | ±0.5 arc-min |
| Repetitive positioning accuracy of P reducer | ±0.5 arc-sec |
| Worktable | |
| Work station | 2 |
- Our COMPACT CJ laser welding machines boast unparalleled configurability, allowing customization to precisely fit the part's geometry.
- Equip with up to four rotary tables to accommodate diverse production needs.
- Choose between automatic operation for streamlined efficiency or manual loading and unloading to suit specific production requirements.
Heat Conduction Welding employs a focused light beam to melt the metal's surface layer, facilitating metal joining.
Deep Penetration Welding, on the other hand, operates in a mode that produces a deep, slim weld seam with a uniform texture by melting the metal and creating a vapor-filled cavity through vaporization.
