SQL Bridge Rectifier
Request a Quote
Model specification
Technical parameters
| Model | Direct current output current | Single-phase input forward average current | Repetitive reverse peak voltage | Repetitive reverse peak current | Isolation voltage |
| A | A | V | mA | V | |
| 40 | 14 | 100-1600 | 7 | 2500 | |
| 60 | 20 | 100-1600 | 7 | 2500 | |
| 100 | 34 | 100-1600 | 7 | 2500 | |
| 150 | 50 | 100-1600 | 10 | 2500 | |
| 200 | 67 | 100-1600 | 10 | 2500 | |
| 250 | 84 | 100-1600 | 10 | 2500 |
Feature
- Current:5-250A
- Voltage:100-1600V
- Small scale common-use sizes
- Vacuum+hydrogen charging protection welding technique
- Glassivation diode core
- Perfect power/volume ratio
- High thermal conductivity package
Dimension and installation style
40A-100A Index
