CNC Vertical V Grooving Machine

CNC Vertical V Grooving Machine
Request a Quote
View All: http://rt-machinetools.com/4-grooving-machine.html
Sheet Metal Grooving Machine

VGM Series

Sheet Metal Grooving Machine

VGM Series

VGM series CNC vertical V grooving machine is designed and manufactured to cater to the specific demands of the mid-to-high-end decoration industry, elevator manufacturing, and other related sectors. The machine excels in performing V grooves on various materials such as stainless steel sheets, iron sheets, and copper sheets, making it an ideal choice for industries that require precise processing of sheet materials, including elevators, decorative materials, stainless steel processing, household appliances, and prop displays. This grooving machine utilizes a working method that involves two sets of six knives for reciprocating grooving, ensuring exceptional efficiency throughout the grooving process.

Features
  • Open control system allows for the addition of new expansion functions, enabling fully automatic processing.
  • Material support rack effectively prevents workpiece scratching.
Parameters

(cutting thickness: 6 to 16mm)

Model Sheet thickness (mm) Sheet length (mm) Sheet width (mm) Max. moving speed of X axis (m/min) Max. moving speed of Y axis (m/min) Max. moving speed of Z/W axis (m/min) Repeat positioning accuracy of Y/X/Z/W axis (mm) X axis servo motor power (kW) Y axis servo motor power (kW) Z/W axis servo motor power (kW) Oil volume (L) Throat depth (mm) Dimensions (L*W*H) (mm) Weight (kg)
VGM1532 0.5-6 200-3200 9-1500 90 10 7 ±0.02 4.4 1.8 0.75/0.75 80 0 5120*3360*2275 10000
VGM1540 0.5-6 200-4200 9-1500 90 10 7 ±0.02 4.4 1.8 0.75/0.75 80 0 5870*3360*2275 11500
VGM1540 0.5-6 200-4200 9-1500 90 10 7 ±0.02 4.4 1.8 0.75/0.75 80 600 5870*3360*2275 13500
VGM1560 0.5-6 200-6200 9-1500 90 10 7 ±0.02 4.4 1.8 0.75/0.75 80 0 7870*3360*2375 18200
Details
  • Backgauge device
  • Hydraulic press
  • Hydraulic clamp device
  • Tool holder
  • Water cooling device
  • Self-lubricating system
  • Integrated hydraulic system
  • Taiwan YiTu CNC system
