Motor Grader, FK-120
Request a Quote
Basic Information
-
- Gross vehicle weight
- 14500kg
-
- Max. blade position angle
- 90°
-
- Main traction force
- 85kN
-
- Blade length
- 3658mm
-
- Rated power
- 154kW
-
- Rated speed
- 2200rpm
- Gross vehicle weight: 14500kg
- Engine model: Yuchai
- Rated power: 154/210kW/HP
- Rated speed: 2200rpm
- Main traction force: 85kN
- Blade cutting force: 7100Kg
- Dimensions (L×W×H): 8850×2600×3330mm
- Wheelbase (front and rear axles): 6300mm
- Wheelbase (middle and rear axles): 1554mm
- Left and right track: 2250mm
- Max. steering angle of front wheels: 50°
- Max. articulation angle: 25°
- Min. turning radius: 7500mm
- Blade length: 3658mm
- Blade height: 610mm
- Max. blade position angle: 90°
- Rotation: 360°
- Blade angle range: 30-65°
- Max. lifting height: 455mm
- Max. penetration depth: 495mm
