Paper Cup Rim Flattening Machine, DESPU-DY800
Request a Quote
Production Efficiency
- Output in every shift (8 hours) achieves 58,000 cups, and monthly output ( in 3 shifts) arrives 4.05million cups.
- Qualified rate is higher than 99% in normal production.
- Machines can be processed simultaneously by single operator.
Quality Control
- 3-year warranty for driving part, and 1-year warranty for electronical parts and wearing parts.
- Easy inspection and maintenance for parts on forming table.
- All parts under forming table should be lubricated every four to six month with specified oil.
Mechanical Properties
DESPU-DY800 paper cup rim flattening machine possesses a working table, which well separated driving part and forming part, and placing driving part inside the chassis under the table. Automatic lubrication is applied in gaps. Parts on table top is designed around the index plate in accordance with the forming technique. PLC control, photoelectric tracking for the whole process are applied for the electronical parts. This machine is quite suitable for the rim flattening of paper cups with a diameter of 60-120mm. It allows an output of 80-120pcs every minute.
Specification
| Model | DESPU-DY800 |
| Output | 80-120 pcs/min |
| Paper cup size | (D1) Φ60-120mm (H) 60-135mm (D2) Φ50-75mm (h) 5-12mm |
| Power | 3-phase 380V，6.5KW |
| Compressed Air | 0.4-0.6MPa，0.2m³/min |
| Weight | 1200kg |
| Packaging Box Size | 1600*1500*2350 |
