Phantom Power Unit
Request a Quote
This phantom power unit provides mono balanced output. It is compatible with various phantom powered microphones.
Technical Specifications of the HT-48V, HT-48V2, HT-320F Pro Phantom Power Unit
Model No. | HT-48V | HT-48V2 | HT-320F Power Switcher Unit |
Input Power | AC 110V/220V | AC 110V/220V | DC1.5V |
Output Power | Phantom power 48V | Phantom power 48V | Phantom power 48V |
Output Current | 6.5mA | 6.5mA | 6.5mA |
Compatible | Phantom power 48V microphone | Phantom power 48V microphone | Phantom power 48V microphone |
N.W. | 0.64kg | 0.64kg | 0.14kg |
Input Type | XLR×1 | XLR×2 | XLR×1 |
Output Type | XLR×1 | XLR×2 | XLR×1 |
Dimension (L ×W×H)mm | 160×104×46 | 160×104×46 | Diameter 22 Length 150 |
Color | Black | Black | Black |
We are a specialized microphone equipment manufacturer based in China. Apart from phantom power unit, we also offer microphone mixer, Feedback Suppressor, true diversity UHF wireless microphone system, wireless voting system, and so on.
