Automatic Pipe Flange Welding Machine (GTAWTIG)

Automatic Pipe Flange Welding Machine (GTAWTIG)
Automatic Pipe Flange Welding Machine (GTAWTIG)
Automatic Pipe Flange Welding Machine (GTAWTIG)
Automatic Pipe Flange Welding Machine (GTAWTIG)
Automatic Pipe Flange Welding Machine (GTAWTIG)
Automatic Pipe Flange Welding Machine (GTAWTIG)
Request a Quote

Model: PFAWC-16Ba/24Ba/32Ba/48Ba/64Ba

Technical Parameters
  • Pipe Diameter Applicable: DN400/DN600/DN800/DN1200/DN1600
  • Pipe Wall Thickness Applicable: 3-20MM
  • Applicable Materials: Carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
  • Welding Line Applicable: Welding line of flange pipe
  • Machine Head System: One welding head with two welding guns at one end/two welding heads with four welding guns both at two ends
  • Driving System: Driven the motor of active idler wheel frame
  • Clamping System: Clamped by chain or contact roller
  • Bracket System: Two sets of motorized idler wheel to be set and it is adjustable according to the pipe length along the track
  • Speed Regulation Mode: VF stepless speed control system
  • Adjustment Mode: Electric cross regulator
  • Swaying System: A product of our patented technology, driven by step motor and oscillating adjusting with digital display
  • Control System: A product of our patented technology
  • Welding Procedure: GTAW/TIG
  • Welding Power: OEM products in China (or as per customers' demands)

Applications
Slip-on flange for the welding of the internal and external incidence angle.

Features
  • The automatic pipe flange welding machine offers excellent welding capacity (150-250 inch/day, which is four times higher than manual welding).
  • The machine is easy to operate.
  • The automatic pipe flange welding machine offers excellent surface forming.
  • It offers a welding compliance rate (without re-working for the skilled operator).
  • The automatic pipe flange welding offers good driving reliability.
  • Classic product; widely used in industries like shipbuilding, mining, irrigation; suitable for welding pipe segments such as “flange pipe flange”; welding efficiency increased by more than 200%; one fixed-type wheel rotator; one movable wheel-supporting trolley; two movable welding trolleys; standard configuration: four Lincoln CV500 inverter welding power supplies; welding synchronously at inner and outer fillet with four MIG welding torches; operated with aluminum alloy control box.
