Cabinet Air Conditioner (Top Mount)

Request a Quote

Website: http://chillers-en.com/6-2-cabinet-air-conditioner-top-mount.html

The cabinet air conditioner is designed for installation on the top of electrical cabinets, making full use of cabinet roof space without occupying the internal area needed for equipment. Using a compressor-based cooling system, it provides efficient and reliable temperature control for electrical control cabinets, servo cabinets, and similar applications. It effectively dissipates heat generated by the equipment, prevents high temperatures and condensation inside the cabinet, and ensures stable operation of sensitive electronic components such as PLC systems and drives, extending equipment lifespan.

Specifications

Model			CAT-450	CAT-630	CAT-900	CAT-1200	CAT-1600	CAT-2000	CAT-2500	CAT-3200
Cooling capacity		W	450	630	900	1200	1600	2000	2500	3200
Cooling capacity		Btu/Hr	1536	2150	3072	4096	5461	6826	8533	10922
Cabinet internal temperature range		℃	15-45	15-45	15-45	15-45	15-45	15-45	15-45	15-45
Ambient temperature range		℃	15-55	15-55	15-55	15-55	15-55	15-55	15-55	15-55
System pressure resistance		bar	26	26	26	26	26	26	26	26
Power supply		V/Ph/Hz	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50	220/1/50
Rated current		A	1.4	1.6	2.6	3.5	4.2	5.3	5.9	6.5
Power input		W	295	355	520	780	905	1150	1300	1450
Internal air flow rate		m³/h	240	330	490	560	580	880	950	1100
External air flow rate		m³/h	450	575	725	860	950	1250	1350	1450
Refrigerant type			R134a	R134a	R407C/R22	R407C/R22	R22/R407C	R22/R407C	R22/R407C	R22/R407C
Internal protection grade			IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
External protection grade			IP30	IP30	IP30	IP30	IP30	IP30	IP30	IP30
Noise level		dB(A)	55	56	56	57	60	62	63	65
Weight		kg	19	22	33	42	45	58	63	76
Dimensions	Length	mm	350	350	370	370	460	460	460	460
	Width	mm	365	365	430	430	518	518	708	708
	Height	mm	395	395	534	534	515	515	515	515
