Uncoiler / Shear Welder / Accumulator

Request a Quote

View All: http://pipemakingmachines.com/2019/6-2-uncoiler-shear-butt-welder-accumulator.html

Uncoiler
1. Double Mandrels Uncoiler
Features: Two mandrels to prepare two coils, automatic rotating, expanding/shrinking/braking using a pneumatic controlled device, with press roller and side arm to prevent coil loosening and turning over

2. Single Mandrel Uncoiler
Features: Single Mandrel to load heavier coils, hydraulic expanding/shrinking, with press roller to prevent coil loosening, comes with a coil car to help coil loading.

3. Double Cone Uncoiler by hydraulic
Features: For heavy coils with a large width and diameter, double cones, with coil car, automatic coil up-loading and centering.

Shear & Butt Welder

The shear & butt welder is used to cut the irregular shaped edges on steel strips or coils and automatic aligning for easier welding.

Type:
1. Pneumatic Shearing, Manual Aligning & Automatic Welding
2. Hydraulic Shearing, Automatic Aligning & Automatic Welding;

Accumulator

Accumulators are necessary for tube mill manufacturing, as they are responsible for temporary material storage and ensures continuous operation. It also protects the steel strip against scratching.

Type:
1. Disc-type Horizontal Spiral Accumulator; (For coils with small thickness and small width)
2. Roll-type Horizontal Spiral Accumulator; (For coil with large thickness and large width)
