GE150H Crawler Excavator
Request a Quote
- Newly-designed negative flow control hydraulic system provides the actuator of the crawler excavator with high response.
- Electronic throttle control enables you to select different control modes according to different loads during operation for high efficiency and energy reduction.
- The hydraulic excavator is outfitted with a high-quality Kawasaki pump and a priority valve to achieve extremely high efficiency.
Consulting Products Information
- An intelligent electronic monitoring system is used for the real-time supervision of the system conditions, enabling the excavator to be maintained easily.
- Our fuel system is constructed using a high-capacity oil water separator and a tertiary filtration system.
- The driver’s cab offers the advantages of a beautiful exterior, large space, a wide viewing angle and superb ventilation conditions. Its silicone-oil damper is ergonomically designed.
- Using a satellite-based GPS system and a remote-controlled fault diagnosis system ensures timely maintenance.
- Adopting an air-conditioning system offers a comfortable operating environment.
Specifications of GE150H Hydraulic Excavator:
| Model | GE150H |
| Length×Width×Height(mm) | 7762×2510×2983 |
| Operating weight (Kg) | 13890 |
| Rated bucket capacity(m3) | 0.6 |
| Max.digging depth(mm) | 5491 |
| Max.digging radius(mm) | 8335 |
| Max.digging height(mm) | 8679 |
| Max.dumping height(mm) | 6174 |
| Bucket digging force(KN) | 100 |
| Stick digging force(KN) | 68 |
| Gradient capacity(%) | 70 |
| Diesel engine | Cummins QSF3.8-C115 |
| Rated output(KW) | 86 |
