Universal automatic Hydraulic servo-controlled tensile testing machine
Request a Quote
Model: TBTUTM-100CSI/300CSI/600CSI/1000CSI
This series of products are mainly used for metal, nonmetal materials tensile, compression, bending, shear and other mechanical properties.
Technical Parameters
TBTUTM-100CSI | TBTUTM-300CSI | |
Capacity: | 100KN | 300KN |
Accuracy degree: | Grade 1 | Grade 1 |
Relative error: | ±1% | ±1% |
Effective measurement range: | 1%-100%F·S(full measurement) | 1%-100%F·S(full measurement) |
Deformation measurement range | 1%-100%F·S | 1%-100%F·S |
Deformation indicate relative error | ±1% | ±1% |
Displacement relative error | ±1% | ±1% |
Displacement measurement resolution | 0.001mm | 0.001mm |
Stress rate relative error | ±2% | ±2% |
Displacement rate control relative error | ±1% | ±1% |
The strain rate control adjustment range | 0.00025/s-0.0025/s | 0.00025/s-0.0025/s |
The strain rate control relative error | ±2% | ±2% |
Stress, deformation & displacement control range | 0.3%-100%F·S | 0.3%-100%F·S |
Stress, deformation & displacement relative error | ≦1% | ≦1% |
Middle beam lifting speed | 320 mm/min | 320 mm/min |
Distance between upper and lower platen | 500mm | 600 mm |
Tensile distance | 600mm max | 700 mm max |
Effective distance between two columns | 380mm | 380mm |
Piston stroke | 200mm | 200 mm |
Piston loading max. speed | 100mm/min | 120 mm/min |
Round specimen diameter | Φ6 mm -Φ22 mm | Φ10 mm -Φ32 mm |
Flat specimen diameter | 0 mm -15 mm | 0 mm -20 mm |
The maximum distance between the bending test | 300mm | 300 mm |
Power supply | 380VAC/220VAC | 380VAC/220VAC |
TBTUTM-600CSI | TBTUTM-1000CSI | |
Capacity: | 600KN | 1000KN |
Accuracy degree: | Grade 1 | Grade 1 |
Relative error: | ±1% | ±1% |
Effective measurement range: | 1%-100%F·S(full measurement) | 1%-100%F·S(full measurement) |
Deformation measurement range | 1%-100%F·S | 1%-100%F·S |
Deformation indicate relative error | ±1% | ±1% |
Displacement relative error | ±1% | ±1% |
Displacement measurement resolution | 0.001mm | 0.001mm |
Stress rate relative error | ±2% | ±2% |
Displacement rate control relative error | ±1% | ±1% |
The strain rate control adjustment range | 0.00025/s-0.0025/s | 0.00025/s-0.0025/s |
The strain rate control relative error | ±2% | ±2% |
Stress, deformation & displacement control range | 0.3%-100%F·S | 0.3%-100%F·S |
Stress, deformation & displacement relative error | ≦1% | ≦1% |
Middle beam lifting speed | 320 mm/min | 320 mm/min |
Distance between upper and lower platen | 600mm | 600 mm |
Tensile distance | 700mm max | 700 mm max |
Effective distance between two columns | 375mm | 455mm |
Piston stroke | 200mm | 200 mm |
Piston loading max. speed | 120mm/min | 100 mm/min |
Round specimen diameter | Φ13 mm -Φ40 mm | Φ14 mm -Φ45 mm |
Flat specimen diameter | 0 mm -20 mm | 0 mm -40 mm |
The maximum distance between the bending test | 300mm | 300 mm |
Power supply | 380VAC/220VAC | 380VAC/220VAC |
