Universal hydraulic servo-controlled machine
Request a Quote
Model:TBTUTM-100C/300C/600C/1000C
Technical Parameters
| Model | TBTUTM-100C | TBTUTM-300C | TBTUTM-600C | TBTUTM-1000C |
| Max. Capacity(KN) | 100 | 300 | 600 | 1000 |
| Range | 2%-100%F.S.(full range, without gear） | |||
| Reading accuracy | Grade1（Grade0.5） | |||
| Error | ±1%（±0.5%） | |||
| Resolution (F.S.) | 1/200000F.S.(1/300000 F.S.) | |||
| Column Number | 4 | 4 | 4 | 6 |
| Width between two column | 345 | 430 | 515 | 510 |
| Max tensile space（mm) | 500 | 600 | 600 | 600 |
| Max compression space(mm) | 500 | 600 | 600 | 600 |
| Bending test Distance between two points(mm) | 100-270 | 100-350 | 100-400 | 100-400 |
| Round specimen clamp diameter(mm) | Ø6-Ø22 | Ø10-Ø32 | Ø13-Ø40 | Ø20-Ø40 |
| Flat specimen clamp thickness (mm) | 0-15 | 0-15 | 0-15 | 0-40 |
| Stroke (mm) | 150 | 200 | ||
| Pistons rise fastest speed(mm/min） | 100 | 80 | ||
| Beam rising speed (mm/min) | 310 | 250 | 250 | 310 |
| Displacement reading relative error | ±1%（±0.5%） | |||
| Deformation reading relative error | ±1%（±0.5%） | |||
| Motor capacity (KW) | 2 | 2.5 | ||
| Main unit dimension (mm) | 665×490×1600 | 740×460×1900 | 850×560×2000 | 960×620×2100 |
| Oil source cabinet dimension(mm) | 1000×600×910 | |||
| Main unit net weight (Kg) | 600 | 1200 | 1750 | 2200 |
