255G Wheeled Skid Steer Loader
Request a Quote
Designed for compact job sites, this wheeled skid steer loader delivers agile performance with a 750kg rated load and 0.43m³ bucket capacity. Powered by an engine with 36.7kW rated power, it delivers reliable handling and 11.5km/h travel speed. Its heavy-duty traction and breakout force ensure efficient handling across light construction, landscaping, and material transport tasks.
- Operating weight 2800 kg
- Dimensions (L×W×H) 3320×1530×2000 mm
- Rated power 36.7 kW/2500 rpm
Technical Specifications
General
- Operating weight 2800kg
- Rated load 750kg
- Bucket capacity 0.43m³
- Tipping load 1504kg
- Breakout force 20.3kN
- Traction force 18.9kN
- Dimensions (L×W×H) 3320×1530×2000mm
Engine
- Engine model Xinchai
- Rated power 36.7kW/2500rpm
- Displacement 3.168L
- Fuel consumption 10.6L
- Stroke 98mm
- Bore 105mm
- Emission NationⅡ
Hydraulic System
- Hydraulic flow 74L/min·2500rpm
- Operation method Pilot operation
- Hydraulic pressure 21MPa
Drivetrain
- Travel speed F&R 11.5km/h
- Tire 10-16.5NHS
Accumulator
- Voltage 12V
- Capacity 120Ah
Tank Capacity
- Chain box 2×9L
- Cooling system 12L
- Engine crankcase 8L
- Fuel tank 83L
- Hydraulic tank 65L
