Universal Testing Machine with LCD screen digital display
Request a Quote
Model: TBTUTM-100B,TBTUTM-300B,TBTUTM-600B,TBTUTM-1000B
The testing machine is mainly designed for metal of tension test, compression test and bending test, also for non-metal of compression test, such as concrete and stone
Technical Parameters
Model | TBTUTM-100B | TBTUTM-300B | TBTUTM-600B | TBTUTM-1000B |
Max. Capacity(KN) | 100 | 300 | 600 | 1000 |
Range | 4%-100%F.S.(Full range, without gear) | |||
Reading accuracy | Grade 1 | |||
Error | ±1% | |||
Column Number | 4 | 4 | 4 | 6 |
Width between two column | 345 | 430 | 515 | 510 |
Max tensile space(mm) | 500 | 600 | 600 | 600 |
Max compression space(mm) | 500 | 600 | 600 | 600 |
Bending test Distance between two points(mm) | 100-270 | 100-350 | 100-400 | 100-400 |
Round specimen clamp diameter(mm) | Ø6-Ø22 | Ø10-Ø32 | Ø13-Ø40 | Ø20-Ø40 |
Flat specimen clamp thickness (mm) | 0-15 | 0-15 | 0-15 | 0-40 |
Stroke (mm) | 150 | 200 | ||
Pistons rise fastest speed(mm/min) | 100 | 80 | ||
Beam rising speed (mm/min) | 310 | 250 | 250 | 310 |
Displacement reading relative error | ±1% | |||
Motor capacity (KW) | 2 | 2.5 | ||
Main unit dimension (mm) | 665×490×1600 | 740×460×1900 | 850×560×2000 | 960×620×2100 |
Oil source cabinet dimension(mm) | 540×540×1300 | |||
Main unit weight | 600 | 1200 | 1750 | 2200 |
Oil source cabinet weight | 210 |
