Temperature Profiling System for Coating Oven
Request a Quote
| Model | SMT-7-128-300-K |
| Channel quantity | 7 for measuring external temperature and 1 for testing the internal temperature of the product |
| Temperature testing range | 0~500ºC |
| Thermocouple | K type |
| RAM | 128 K |
| Resolution | 0.3ºC |
| Measuring accuracy | 0.5% |
| Size | Φ76×200mm |
| Using temperature and time | It can be used continuously for 600minutes at 100ºC, 120 minutes at 200ºC or 60 minutes at 300ºC. |
| Recording time | It records the data once eight seconds for 15 hours. |
| Sampling cycle | 1s, 2s, 3s, 5s, 8s, 10s, 12s, 20s, 40s, 60s |
| Thermal barrier size | 280(length) ×120(width) × 100(height)mm |
| Setting software (Trend Reader V1.22 ) | 1. It allows selecting or unselecting all the channels. 2. The standardized time of each channel is verified independently to address the demands on precision. 3. The sampling cycle is optional. 4. It brings convenience for start or stop. |
| Analysis software (Trend Reporter V1.0) | 1. The display of all the curves can be selected. 2. It can calculate the heating rate between two temperature levels. 3. The software is able to give the stopping time above some 4 different temperature levels. 4. It helps to get the peak temperature. 5. It can compare the data of 2 to 5 times of testing. 6. Report printing |
| |
| SMT-7-128-300-K temperature profile system for coating oven | Analysis software interface |
