Carbon-based Polyester Fiber Filter Cartridge, PTS Series
Request a Quote
Filter elements for battery electrode slurry filtration
Our carbon-based polyester fiber filter cartridge is specifically designed for use in powder material transfer systems, employing high-quality carbon-based polyester fiber. The precision of the filter medium ensures efficient particle interception during backwashing, preventing dust particles from leaking and affecting the stability of vacuum pumps and equipment operation. The carbon-based material on the filter medium's surface further enhances filtration efficiency by trapping dust particles on the outer surface of the filter, resulting in higher backwashing efficiency and extended filter lifespan.
Materials of Construction
| Center Rod/Housing/End Cap | Galvanized Carbon Steel/Stainless Steel |
| O-ring | Silicone Rubber |
Specifications
| Model | PTS |
| Filter Length | Customizable to match your equipment |
| Filter Medium | H13-grade Carbon-Based Polyester Fiber |
| Max. Differential Pressure | 0.4Mpa |
| Max. Operating Temperature | 150℃ |
Features
- High-performance carbon-based material with an activated carbon coating enhances filtration efficiency while trapping dust particles on the outer surface of the cartridge.
- High backflushing efficiency extends the lifespan of the filter cartridge.
- High particle capturing capability, providing up to 99.99% particle interception efficiency.
- Multiple filtration precision options available, catering to diverse filtration needs.
- Customizable based on specific applications and customer requirements.
Applications
- Vacuum loading systems for efficient material transfer.
- Powder transfer systems requiring precise filtration.
- Decarbonization and fine filtration of materials.
- Impurity removal during raw pharmaceutical material production.
