LVDS Linear Variable Inductive Displacement Sensor
LVDS series linear variable inductive displacement position sensors are contactless devices designed for factory automation and a variety of industrial and commercial applications such as solar cell positioners, wind turbine prop pitch and brakes, chute or gate positions on off-road or packing equipment.
With their compact design, superior performance, and excellent stroke-to-length ratio, the LVDS sensors are ideal for both industrial testing, laboratories, and in-plant or mobile equipment OEM applications.
LVDS sensors are offered in 10 full scale ranges from 20 to 200 mm. Operating from a variety of DC voltages, these sensors offer a choice of outputs and all include the field programmability calibration feature. LVDS position sensors come with radial exiting cable and two swivel rod eye ends for easy installation if required.
- Contactless device heavy-duty, long lasting
- High accuracy with low linearity error, 0.25% full scale deflection
- Hermetically sealed design
- Reliability with high-strength materials
- Radial cable exit and swivel rod eye ends are optional
- Designed to operate under adverse temperature, vibration, shock, and humidity conditions
- Flight control actuators for fixed and rotary wing aircraft
- Engine fuel metering valve position
- Engine variable geometry actuators
- Thrust reverser actuation system
- Engines (mechanisms valves)
- Nose-wheel steering for Engineering vehicle
| Model | ||
| Power Voltage | 12 to 30VDC | 5-12VDC |
| Analog Output | 4 to 20 mA (3-wire) output, 60 mA max 75℃ (167°F max) | 0.5-4.5V (3-wire) output, 60 mA max 85℃ |
| Measuring Range | 20-200 mm full scale | 20mm full scale |
| Linearity Error | ±0.15% of full scale | ±0.15% of full scale |
| Output Precision | Typical ±0.25% max | Typical ±0.25% max |
| Resolution | 0.025% of full scale | 0.025% of full scale |
| Update Rate | 300 Hz nominal | 300 Hz nominal |
| Operating Temperature | -20 to 85℃ (-4 to 185°F) | -20 to 85℃ (-4 to 185°F) |
| Temperature Coefficient | 0.015% of FS/℃ | 0.015% of FS/℃ |
| Vibration | 5 to 20Hz, 0.5" p-p 20 to 2000 Hz, 4.2g p-p | 5 to 20Hz, 0.5" p-p 20 to 2000 Hz, 4.2g p-p |
| Shock | 1000g, 11ms | 1000g,11ms |
| Protection Class | IP67 | IP65 |
| Humidity | 95% RH, non-condensing | |
| EMC Compatibility | Environmental EMC compatibility test ISO018189 | |
| Housing Material | 38mm diameter SS304 Housing | 22mm diameter SS304 Housing |
| Testing Rod | M6 thread or rod eye ends (optional) | |
| Cable | PUR cable, 2m or client required | |
Note: dual or four redundant channels can be customized
