The HD-ATT60 aircraft towing tractor is capable of trundling or dragging a variety of CRJ aircraft, including Boeing B727, B737, B757, Airbus A300, A310, A319, A320, McDonnell MD-82, MD-90 and other aircraft weighing less than 150 tons.

The aircraft towing tractor consists of the frame, drive system, engine system, air conditioning system, dual oil system, hydraulic system, cab, electrical system and flat system.

Technical Specifications of Aircraft Towing Tractor

Product Model	ATT60 A	ATT60 B
Traction Power	120KN	125KN
Maximum Tractive Tonnage	15T	20T
Steering Modes	Four-Wheel Steering	Four-Wheel Steering
Vehicle Length	5430mm	5430mm
Vehicle Width	2080mm	2080mm
Vehicle Height(Cab)	1990mm	1990mm
Ground Clearance	210mm	210mm
Minimum Turning Radius(Inside)	3300mm	3600mm
Minimum Turning Radius (Outside)	8800mm	8800mm
Wheel Base	2200mm	2200mm
Track (Front/Rear)	1790mm	1790mm
Approach Angle	15°	15°
Departure Angle	15°	5°
Maximum Forward Speed	25km/h	25km/h
Maximum Back Speed	20km/h	20km/h
Curb Weight	15960kg	15200kg
Maximum Gradability	25°	25°
Maximum Braking Length	3.4M	3.4M

Engine Model/ Brand	Perkins:1044TA/ Perkins	TD3.6L4/DEUTZ
Power	74.5KW/2400	74.9KW/2500
Torque	230 Nm	186 Nm
Diesel Consumption	215 g/Kw.h	220 g/Kw.h
Gearbox Model/ Brand	DANA T12465 (4 Forward Gear 3Reverse Gear )	DANA T12465 ( 4 Forward Gear 3Reverse Gear
Front axle Model/Brand	DANA212 Steer /Drive Axle(Leaf Spring Damping)	DANA212 Steer /Drive Axle(Leaf Spring Damping)
Rear Axle Model/ Brand	DANA212 Steer /Drive Axle	DANA212 Steer /Drive Axle
Hydraulic Oil Tank	80 L	80 L
Diesel Tank	90 L	90 L
Electrical System	24VDC	24VDC

Feature of Aircraft Towing Tractor

Cab
1) The cab is fully enclosed, and uses an easy to operate power hydraulic system.
2) The cab includes a variety of instruments, gauges, indicator lights and other clear digital displays.
3) The cab is equipped with an air conditioner, backwards movement image system, radar and other features.
The tractor body is built using a high strength, thickened steel plate and a counterweight steel plate, thus ensuring tractor stability and safety.
The aircraft towing tractor uses DEUTZ engines or Perkins engines, both of which feature a high power with low emission levels. These tractors easily provide trundle or drag operations for narrow body and medium sized aircraft.
The tow tractor uses DANA T12465 gearbox, which is a power shift gearbox with a torque converter: 4 gears forward and 3 reverse.
The two ends of the tractor body are equipped with a 70mm diameter traction pin so that the user can manually control the hook device.
Brake characteristics: double circuit /quattro hydraulic drive / disc brakes in the oil
Parking brake characteristics: rear wheel hydraulic brake /disc brakes in the oil
Steering mode: quattro hydraulic control steering
