CNC Slot Milling Machine
Request a Quote
Our CNC slot milling machine is an affordable, high speed and accurate machine suitable for threading, grooving and drilling of a variety of wood furniture, and is designed with 4 different positions to ensure a continuous, efficient timber machining. The CNC slot milling machine also utilizes an advanced, numerical control system, making it consistently accurate and easy to operate.
Specification| Model | MD-3841 | MD-3842(4+4) |
| Maximum width of machining | X Axis: 3800mm | X Axis：3800mm/3600mm |
| Y Axis: 450mm/120mm | Y Axis: 450mm/120mm | |
| Z Axis: 140mm | Z Axis: 140mm | |
| Maximum speed of movement | X Axis: 60m/min | X Axis: 60m/Min |
| Y Axis: 30m/min | Y Axis: 30m/Min | |
| Z Axis: 15m/min | Z Axis: 15m/Min | |
| Maximum machining speed | 10m/min | 10m/min |
| Spindle power | 3.7KW*4 | 3.7KW*4+2.2kw*4 |
| Spindle speed | 18000r/min | 18000r/min |
| Total installed power | 19KW | 28KW |
| Total weight | 2950kg | 3050kg |
| Installation dimension | 4500*2850*2150mm | 4500*2850*2150mm |
