Household & Daily Chemical Filling Line
Automatic filling, capping and labeling system for shampoo, liquid soap, detergent, and household cleaners
- For filling volume ≤ 1000ml: Accuracy ±2–3ml/g
- For filling volume ≤ 5000ml: Accuracy ±3–5ml/g
- Production Capacity: 720–7200 BPH (Bottles Per Hour)
Designed specifically for medium-to-high viscosity products such as body wash/shower gel, shampoo, lotions, and detergents, this household & daily chemical filling line utilizes stable and reliable piston filling technology to achieve a For filling volume ≤ 1000ml: Accuracy ±2–3ml/g, For filling volume ≤ 5000ml: Accuracy ±3–5ml/g and support 2–20 anti-drip nozzles, making it suitable for PET, HDPE, and glass bottles across various filling capacities.
The entire line features a SUS304 stainless steel frame and SUS316L contact parts, complying with GMP hygiene standards for exceptional durability and ease of cleaning. Equipped with an advanced PLC touch screen HMI, it allows for intuitive parameter adjustments, precise volume control, and "No Bottle, No Fill" detection. This all-in-one solution seamlessly integrates filling, capping, and labeling for maximum efficiency. It is your ideal choice for home care and daily chemical industries.
| Filling Nozzles | 2-20 heads (optional) |
| Filling Speed | about 720-7200bottles/hour |
| Filling Accuracy | Filling volume≤1000ml, filling accuracy ±2~3ml/g Filling volume ≤5000ml, filling accuracy ±3~5ml/g |
| Filling Form | Servo piston filling |
| Program Control | PLC & Touch Screen |
| Material Contact Part | 304/316 stainless steel |
| Air Pressure | 0.6-0.8MPa |
| Feed Tank Capacity | 150L (depends on the machine size) |
| Protection Device | Filling material shortage shutdown and alarm |
- Automatic Piston Filling Machine
- Automatic Spindle Capping Machine
- Automatic Front & Back Labeling Machine
