Request a Quote

Features

  • All steel construction raised basement;
  • Full downdraft airflow style, ensuring turbulence-free airflow path;
  • Illumination brightness reaches 1000 lux;
  • Oil fuel heating (gas-fired heating, electric central heating, hot water heating and steam heating are optional);

Specifications

  • Exterior dimensions: 7.0×5.3×3.5m
  • Interior dimensions: 6.9×3.9×2.7m
  • Access door width: 3.0m
  • Access door height: 2.66m
  • Airflow: 18,000m 3 /h
  • Air speed: 0.25-0.30 m/s
  • Power: approx. 13kw
  • Applicable vehicle: sedan car

Standard Configurations

  • Basement: all steel construction raised basement, 2-row grating 3-row checkered plate;
  • Fan unit: one 5.5kw intake fan, one 5.5kw exhaust fan;
  • Heating: Riello G20 burner, with heat exchanger;
  • Lighting system: upper lights are 8*4*18W LED light tubes, lower lights are 8*2*18W LED light tubes;
  • Wall panel: EPS insulated wall panel, thickness 50mm;
  • Ceiling structure: welded ceiling frame;
  • Roof panel: single-skin galvanized steel roof panel;
  • Electric control: phase loss protection, overheat protection and overload protection, direct starting of motor;
Full downdraft
Side downdraft (optional)
Crossdraft (optional)
EPS insulated wall panel
All steel construction raised basement (2-row grating 3-row checkered plate)
Riello G20 burner
Welded ceiling frame
European-style fan
Air inlet cotton
