WN203WA170X170 Motorized XY Linear Stage
Request a Quote
WN203WA170X170 motorized XY linear stage is designed in biaxial form, the two orthogonal axes form angle with good accuracy. Driven by high quality ball screw, the stage has high repeatability and driving power. Equipped with crossed-roller bearing and precision grinding V-shaped guide rail, the stage can move stably and has high precision and long lifespan. The travel is 170 mm; table size is 300×300mm; maximal speed is 25mm /sec; load capacity is 60kg.
| Model | WN203WA170X170 | |
| Structure | Travel | 170 mm |
| Table size | 300×300mm | |
| Screw type | High precision ball screw(lead 4 mm) | |
| Guide rail | Crossed-roller bearing | |
| Stepper motor (1.8°) | STP-42D3016 | |
| Material | Aluminum alloy | |
| Surface | Blackened by anodic oxidation | |
| Load capacity | 60 kg | |
| Weight | 10.3kg | |
| Accuracy | Resolution | 20μ(Non-MS driver) 1μ(20 MS driver) |
| Maximum speed | 25mm /sec | |
| Repeatability | 2μ | |
| Positional accuracy | 3μ | |
| Straightness | 5µ | |
| Driving parallelism | 15µ | |
| Pitching | 50″ | |
| Yawing | 25″ | |
| Backlash | 2µ | |
| Step-out | 2µ | |
| Able to add grating scale(G) | ||
| Able to change servo motor(D) | ||
