Monocrystalline Solar Panel 60P, 280W-295W PV Module

Monocrystalline Solar Panel 60P, 280W-295W PV Module
Monocrystalline Solar Panel 60P, 280W-295W PV Module
Request a Quote
  • 60

    60 Monocrystalline Cells

  • 280W-295W

    Power output

  • 0~ 5W

    Power tolerance

Features
  • Designed according to the International Electrotechnical Commission standards, including
    IEC61215:2005 and IEC61730:2004. Through the use of tests and demonstrations, the component quality, electrical properties and service life requirements are guaranteed.
  • High efficiency crystalline silicon solar cells are used.
  • Long service life:≧25 years, with low degradation rate.
  • The solar cell frame has screw-less concealed corner braces connected to the corners, featuring high intensity and optimal tightness.
  • Surfaced with a high transmittance toughened glass, with high mechanical strength.
  • Sealed waterproof multi-functional junction box is used to ensure the safety of components.
  • Certified to withstand high wind loads, snow loads and more.
  • High salt mist and ammonia resistance, free from the influence of environment.

JIEYANG produces a variety of solar panel components, including dual glass panel components in a variety of specifications to meet customer needs.

Parameters
Type JY-280-60M JY-285-60M JY-290-60M JY-295-60M
Rated Maximum Power at STC 280 285 290 295
Open Circuit Voltage (Voc/V) 38.5 38.6 38.8 38.9
Maximum Power Voltage (Vmp/V) 31.4 31.5 31.7 31.8
Short Circuit Current (Isc /A) 9.45 9.59 9.71 9.85
Maximum Power Current (Imp/A) 8.92 9.05 9.15 9.28
Module Efficiency (%) 17.1 17.4 17.7 18.0
Power Tolerance(W) -0~ 5
Temperature Coefficient of Isc (αIsc) 0.059%/℃
Temperature Coefficient of Voc(βVoc) -0.330%/℃
Temperature Coefficient of Pmax(γPmp) -0.410%/℃
STC Irradiance 1000W/ m², Cell Temperature 25℃, Air Mass 1.5
