Request a Quote

63mm-200mm Plastic Pipe Welding Machine

The manually operated pipe jointing machine is suitable for butt fusion welding of HDPE, PP, PVDF, and other plastic pipes.

  • Model: WP200C
  • Welding range: 63-200 mm
  • Applicable pipe diameters: 63-75-90-110-125-140-160-180-200 mm
  • Power supply: 220 V/50Hz, 1PH
  • Total power: 2.9 kW
  • Heating plate: 1.8 kW
  • Planing tool: 1.1 kW
  • Max temperature of heating plate: 270 ºC
  • Temperature deviation: ±5 ºC
Application

WELPING high quality manual butt fusion machines are suitable for welding HDPE, PP, PVDF, MPP pipelines.

Features
    1. The manual butt fusion equipment features a sturdy and distortion-free machine frame which is ideally suitable for heavy-duty operations.

    1. Hand-operated transmission mechanism delivers smooth, stable, effortless, and efficient operations.

    1. Copper coil motor has a self-locking system to prevent damages caused by misoperation. High-speed steel reducer inserts with double cutting edges are highly durable.

    1. The pipe butt fusion equipment employs superior resistance wire for efficient and even heating performance. The heating element is finished with high-quality Dupont or Daikin coating.

Packaging & Shipping
Tags
  • manual butt fusion equipment
  • butt welding machine
  • pipe fusion machines
  • pipe jointing
  • butt fusion welding machine supplier
  • plastic welding machines
