Stand Up Reach Truck
Stand up reach truck is affordable, easy to operate and suited to working in even ground.
Technical ParametersModel | FBR15/18ST | FBR20ST | FBR25ST | |||
General | Power Type | Battery | ||||
Load Capacity | kg | 1500/1800 | 2000 | 2500 | ||
Load Centre | mm | 500 | 500 | 500 | ||
Service Weight | kg | 2700/2850 | 3100 | 4450 | ||
Chassis | Tyre | PU | PU | PU | ||
Number of wheels front/rear(x = driven wheels) | 2/1X | 2/1X | 2/1X | |||
Front Tyre | 267x135 | 267x135 | 285x135 | |||
Rear Tyre | 310x120/150X60 | 343x140/150X60 | 343x140/150X60 | |||
Track width, front | mm | 1113 | 1185 | 1185 | ||
Track width, rear | ||||||
Wheelbase L1 | 1585.5 | 1585.5 | 1585.5 | |||
Reach Distance O | 600 | 600 | 600 | |||
Dimension | Lift Height H | 3000-8000 | 3000-8000 | 8000 | ||
Fork Size | L4×W×T | 1070×120×35 | 1070×120×40 | 1070×120×40 | ||
Mast Tilt Angle | Fα/Rβ | 3/5 | 3/5 | 2/4 | ||
Mast Lowered Height H1 | mm | 2080(2236S450) | 2080 | 3790(S800) | ||
Mast Extended Height(with backrest) H2 | 4032 | 4032 | 9072 | |||
Width over forks(outside) W5 | 240-800 | 240-800 | 240-800 | |||
Length to face of fork(Without fork/With fork) L | 2095 | 2095/3206 | 2095/3206 | |||
Overall Width W2 | 1260 | 1260 | 1320 | |||
Overhead Guard Height H4 | 2157 | 2157 | 2157 | |||
Assist Grip Height H7 | 1025 | 1025 | 1025 | |||
Front Overhang L4 | 250 | 280 | 280 | |||
Min. Turning Radius Ra | 1860 | 1880 | 1880 | |||
Ground Clearance(Bottom of mast) H5 | 80 | 80 | 80 | |||
Min. Stacking Aisle width for Pallets 1000X1000RASA | 2680 | 2830 | 2080 | |||
Min. Stacking Aisle width for Pallets 1200X1200RASA | 2880 | 3030 | 2180 | |||
Performance | Max. Travel Speed(Full load/Empty load) | km/h | 8/10 | 8/10 | 8.5/9 | |
Max.Lifting Speed(Full load/Empty load) | mm/s | 310/400 | 280/300 | 220/280 | ||
Max. Lowering Speed(Full load/Empty load) | ≤430/≥320 | ≤450/≥320 | ≤500/≥320 | |||
Max. Gradeability(Full load) | % | 12 | 12 | 10 | ||
Power | Battery (voltage/capacity) | V/Ah | 48/375 | 48/400 | 48/400 | |
Battery Size | L×W×T | mm | 1000×400×600 | 1000×400×600 | 1000×400×600 | |
Engine power | Travel(Drive motor) | Kw | 5 | 5 | 5 | |
Lifting(Lift motor) | 11 | 11 | 11 | |||
Type of drive control | AC |
