Dual Cylinder Oil Pan Filter Manufacturer

Dual Cylinder Oil Pan Filter

Request a Quote

View All: http://ship-machinery.com/1-2-2-dual-cylinder-oil-pan-filter.html

Application

The SPL dual-cylinder oil pan filter is intended for the filtration of lubricating oil and fuel oil mediums used in marine diesel engines and stationary diesel engines.

Characteristics

DPL single-cylinder oil pan filter features a large filtration area, which offers better oil penetrability and lower pressure.
The oil pan filter can be easily maintained, with no frequent washing necessary.
Equipped with a differential pressure clogging indicator, the pressure difference is shown instantly. When the value reaches certain value, it will automatically alarm to remind you of clearance.

Parameters for SPL15, SPL20, SPL25, SPL32 and SPL40 dual-cylinder oil pan filter

TYPE	Nominal diameter (mm)	Mounting type	Outline dimensions (mm)			Distance of disassembly (mm)	Connecting dimensions of pipe (mm)		Mounting dimensions of pipe (mm)					Mounting dimensions of base							Net Weight (Kg)
	DN		H	B	L	H1	D	D0	C	h	L3	B1	H2	h1	L1	L2	b	R	n	d1
SPL15	15	C	328	180	196	260	M30X2 CB500-75		38	55	88	155	291	45	166	80	12	16	4	12	9.5
SPL20	20	C	310	207	260	230	M33X2 CB500-75		34	65	90	177	258	90	230	100	12	15	4	15	11.5
SPL25	25	D	315	323	230	270	M39X2 CB500-75		34	65	90	185	265	70	156		12	15	2	16.5	12
SPL25	25	C	315	205	260	270	M39X2 CB500-75		34	65	90	177	265	50	230	100	12	15	4	16.5	12
SPL32	32	D	380	232	200	330	60X60	38	34	65	96	187	330	70	170		12	15	2	16.5	12
SPL32	32	C	380	207	260	330	60X60	38	34	65	96	175	330	50	230	100	12	15	4	16.5	12
SPL40	40	C	462	261	314	360	60X60	45	43	70	110	224	363	100	274	130	15	20	4	17	22
Notice: For installment, D is hanging while C is side placing. Differential pressure clogging indicator can fluctuate.

Parameters for SPL50, SPL65 and SPL80 dual-cylinder oil pan filter

TYPE	Nominal diameter (mm)	Mounting type	Outline dimensions (mm)			Distance of disassembly (mm)	Connecting dimensions of pipe (mm)		Mounting dimensions of pipe (mm)					Mounting dimensions of base(mm)							Net Weight (Kg)
			H	B	L	H1	D	D0	C	H	L3	B1	H2	h1	L1	L2	b	R	n	d1
SPL50	50	X	447	425	410	425	86X86	57	220	90	140	355	422		260	210	18	25	4	20	85
		C		400								355	412	92	350	130
SPL65	65	X	580	453	410	535	100X100	70	365	105	160	375	527		260	210	20	25	4	20	120
		C		423								370	517	112	350	150
SPL80	80	X	780	541	492	660	116X116	89	443	124	190	456	650		350	270	20	25	4	22	165
Notice: For installment, X is underneath placing while C is side placing. SPL80 is equipped with lifting system (Seen Figure 1). Differential pressure clogging indicator can fluctuate.

Parameters for SPL100 and SPL125 dual-cylinder oil pan filter

TYPE	Nominal diameter (mm)	Outline dimensions (mm)			Distance of disassembly (mm)	Connecting dimensions of pipe (mm)		Mounting dimensions of pipe (mm)					Mounting dimensions of base (mm)						Net Weight (Kg)
	DN	H	B	L	H1	D	D0	C	h	B1	L3	H2	L1	L2	b	R	n	d1
SPL100	100	765	847	560	660	190	108	336	200	687	300	640	500	330	20	32	4	22	370
SPL125	125	850	900	605	760	215	133	420	225	732	340	730	540	370	20	32	4	22	420
Notice: The standard for flange is GB573. Differential pressure clogging indicator can fluctuate.

Parameters for SPL150 and SPL200 dual-cylinder oil pan filter

TYPE	Nominal diameter (mm)	Outline dimensions (mm)			Distance of disassembly (mm)	Connecting dimensions of pipe (mm)		Mounting dimensions of pipe (mm)					Mounting dimensions of base (mm)						Net Weight (Kg)
	DN	H	B	L	H1	D	D0	C	h	B1	L3	H2	L1	L2	b	R	n	d1
SPL150	150	890	1000	990	790	240	159	380	250	825	400	760	750	460	30	32	4	22	680
SPL200	200	1058	1155	1180	945	310	219	450	315	960	440	910	920	520	30	40	4	24	800
Notice: The standard for flange is GB573-65. There are 3 units of filter element for DN150 and 4 units of filter element for DN200. Differential pressure clogging indicator can fluctuate.
