Due to the machine’s automatic electric chuck and claw DC motor drive, the clamping motor current is adjustable and stable, giving it a wider clamping range with greater force. It carries out non-destructive pipe clamping and automatic centering and clamping of the pipe. The chuck features a smaller size with low rotation inertia and strong dynamic performance.

iLoader – the automatic loading device increases processing efficiency by up to 80% compared to manual operation. The swing arm position is controlled with outstanding precision and it allows a rotation of 120° for greater flexibility when paired with the equipment. A safety sensor module is equipped to prevent any accidents.

The operating system of the automatic laser cutter produces an intelligent layout for graphics cutting and supports the importing of multiple graphics, optimizing performance. The control system provides an intuitive operating experience, enhancing the utilization of the workpieces and ultimately reducing waste and saving money.

The bed of this machine is made from flake graphite cast iron with a tensile strength of 200MPa. The material is chosen because of its high compressive strength and hardness, ensuring excellent stability and wear resistance. The laser cutting machine will always maintain high precision.

The crossbeam of the laser cutter is produced using lightweight and rigid aluminum. Each crossbeam is processed with integral steel mold pressure casting and will undergo artificial aging, solution treatment, and finishing to improve its rigidity, surface quality, and ductility. The crossbeam is perfect for adapting to the high speed movements during processing.

The automatic nozzle changer features an accurate control system to replace nozzles according to different materials and thicknesses automatically, eliminating the need for time costly manual replacement. The system also enables automatic calibration and cleaning functions. The high-precision drive system provides reliable replacement precision and stability. The fully enclosed device maximizes operator safety.

Operated by the machine tool control system, the laser head can produce lasers with various focal lengths. When adjusted during the cutting process, the focal length of the laser can achieve different cutting effects. You will make adjustments based on material type and thickness. When switching to different materials, the auto focus laser head will read the system storage parameters to adjust to the proper focal length for the job.
The device comes with built-in double water cooling structures that regulate the temperature to protect the lenses from overheating. A collimation protective lens and focus protective lens are equipped to protect key components and maximize processing safety.

Featuring Bodor Lightning technology, the perforation time is reduced by up to 90% compared to traditional techniques. Bodor Lightning combined with Bodor Genius improve the process so that perforation is not affected by the material quality and the machine can complete perfect cutting.

The size of your smart phone, this wireless remote can be used to operate this high precision equipment with just one hand. The remote is magnetic so simply fix it to the machine when not in use.

The modern 21.5 inch touch display allows for the clear display of machine parameters and the touch function enables more intuitive operation. The 10 point touch technology is accurate, improving the operator experience.

Raising and lowering the subsidiary roller table reduces the friction between parts and the working table. This facilitates more convenient loading and unloading.

The system will sound an alarm if the pressure is lower than the optimal level for cutting and precision. This helps the operator to ensure cutting performance with greater accuracy through timely gas replacement.

Real-time feedback anywhere, including fault analysis and troubleshooting operations.

This allows operators to automatically monitor the operation range of the crossbeam and cutting parts. This greatly improves the equipment performance and safety of the users.

This system provides the necessary lubrication oil for the equipment at predetermined times and volumes to maintain high performance and safety. It will alarm if any abnormalities or low liquid levels are detected. The system greatly enhances cutting precision and maximizes the service life of the machine.

This device ensures the laser head maintains a safe distance from the workpiece to prevent collision. If contact is made, the machine will automatically stop to protect valuable components. The module minimizes the failure rate and improves cutting performance.

In the case of any abnormality, the system will sound an alarm that will be displayed through the control center. This will help operators quickly find the cause of the problem and minimize downtime.
