Steel H Beam Overturn Machine
Description
The steel H beam overturn machine adopts chain for overturn. It is equipped with four electric hoists controlling chain lifting and four travel carriages which can drive the left and right movement of the electric hoists. The left and right movement of the travel carriage can realize left and right transportation of H beam of various sizes. The synchronous lifting of the chains controlled by electric hoists can realize 180 degree overturn of the H beam, so it is suitable for 180 degree overturn of H beam of which one side is welding finished. Thus the welding of another side carried out by the next submerged arc welding machine can be quite convenient.
| Applicable H beam length | 5 ~ 15 m |
| Applicable H beam width | 150 ~ 500 mm |
| Applicable H beam height | 300 ~ 1200 mm |
| Applicable H beam weight | ≤ 4 t |
| Lifting speed | 6000 mm/min |
| Moving speed | 8000 mm/min |
| Base machine power | 7.2 kW |
| Base machine total width | 4500 mm |
| Base machine total length | 5350 mm |
| Base machine total height | 4410 mm |
Features
1. The movements of various devices of the steel H beam overturn machine are controlled by operation box and electric system, so that it has convenient and reliable operation and small labor intensity.
2. This machine is equipped with charged magnetic brake pad and gear motor. Thus the H beam will remain at the position whenever power failure occurs during the lifting, overturn and left and right movement of the H beam, but not loosing control by traction because of power failure, thus greatly improving the safety and controllability of the machine.
3. The machine rack adopts frame structure. The column adopts square tubes so that it has good appearance and stress resistance. Meanwhile, it has less floor area. The cross beam is H-shaped, so the bending resistance of the beam is greatly improved.
4. The lateral movement of travel carriage is driven by the gear rack, so that the left and right movement of the travel carriage can be precisely controlled. It can prevent the carriage sliding caused by force at the same time.
