Plush Fabric Warp Knitting Machine
Request a Quote
GE2885 Raschel Machine
Double needle bar raschel knitting machine for producing plush fabrics used in plush toys, blanket, apparel and home upholstery
Applications
Short, medium, and long pile fabrics used in plush toys, apparel, home upholstery, decorative fabrics, and blankets, etc.
Features
- High speed plush fabric warp knitting machine uses an oil immersed cam-linkage mechanism and fixed ground bars.
- Raschel warp knitting machine has functions of electronic guide bar control (EL), electronic yarn let-off, remote control and online diagnostic.
- The plush has a pile height of 3-25mm.
Specifications
- Needle type Individual latch needle, block latch needle
- Gauge E16, E18, E22
- Number of bars 5 bars
- Distance between knocking-over bar 6-50mm
- Working width 90"/100"/110"/138"/ 150"/158"/170"/184"/210"
- Max. speed 700 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 3700×6050×3750 | 22.6 | 8000 | 9.5 | |
| 4000×6050×3750 | 24.5 | 9250 | 9.5 | |
| 4350×6050×3750 | 26.4 | 10000 | 10.5 | |
| 5100×6050×3750 | 30.3 | 12000 | 12 | |
| 5100×6050×3750 | 30.3 | 12000 | 14 | |
| 5300×6050×3750 | 32.1 | 12500 | 15.5 | |
| 6100×6050×3750 | 36.9 | 14500 | 15.5 | |
| 6550×6050×3750 | 39.6 | 15250 | 17.5 | |
| 7250×6050×3750 | 43.9 | 16500 | 24.7 |
