Plush Fabric Warp Knitting Machine
Request a Quote
GE2296 Raschel Machine
Double needle bar raschel knitting machine for producing plush fabrics used in bra, apparel and car interior upholstery
Applications
Elastic linings, three-layer spacer fabrics, high-density ultra-fine short plush fabrics used in bras, apparel, car interior upholstery, eco-friendly filtering materials, etc.
Features
- Jacquard spacer fabric warp knitting machine uses an optimized cam connecting rod mechanism.
- The spacer fabric warp knitting machine adopts a four-bar-linkage mechanism for knitting process.
- The textile machinery utilizes short-stroke tongue needles for faster weaving speed and fabric output speed.
- Jacquard spacer fabric warp knitting machine has functions of electronic yarn let-off, electronic fabric take-up, and independent batching.
Specifications
- Needle type Block latch needle
- Gauge E30, E32
- Number of bars6 bars
- Distance between knocking-over bar 2-16mm
- Working width 90"/100"/110"/138"/170"/210"
- Max. speed 800 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 4100×5500×3400 | 22.55 | 8000 | 8.25 | |
| 4450×5500×3400 | 24.475 | 9250 | 12.5 | |
| 4800×5500×3400 | 26.4 | 10000 | 12.5 | |
| 5500×5500×3400 | 30.25 | 12000 | 14.75 | |
| 6100×5500×3400 | 33.55 | 14500 | 21 | |
| 8300×5500×3400 | 45.65 | 17500 | 21.5 |
