Single Facer, SF-DW10

Single Facer, SF-DW10
Request a Quote

This product has been discontinued and removed from our shelves.

Corrugated Board Manufacturing

    1. Max. design speed
      100m (3937.01")/min
    1. Working width
      1600mm(62.99")-1800mm(78.74")
    1. Heat source
      steam, electricity, liquid gas
    1. Diameter of corrugating roll
      280mm (11.02")

Features

  • Paper feeding is carried out by using vacuum absorption method, a high-pressure blower is equipped to ensure the stable corrugation process at high speed;
  • The width of groove on lower corrugating roll is less than 2mm, efficiently preventing the marks of stripes on corrugated cardboard;
  • Universal joint transmission system is adopted to reduce vibration, enabling the operation more stable and reliable;
  • Reduction gearbox is designed with oil-immersed lubrication to lower the machine vibration;
  • Automatic glue feeding, pneumatic control of glue application and return can provide cushion effect;
