GE2396 Raschel Machine

Double needle bar raschel knitting machine for producing apparel fabrics, swimwear fabrics and medical fabrics

Applications

Seamless products, pantyhose, gloves, sportswear, swimwear, knitted tapes, medical bandages, etc.

Features
  • Intelligent technology, three-dimensional weaving, one-step forming.
  • Clothing warp knitting machine adopts an optimized eccentric-links mechanism.
  • The warp knitting machine has functions of electronic yarn let off at multi-stage and variable speeds and electronic fabric take-up.
  • Application of jacquard pattern technology can produce cylindrical goods and seamless products.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E22, E24, E28, E30
  • Number of bars 4 bars (2 ground bars, 2 jacquard bars)
  • Number of bars 6 bars (4 ground bars, 2 jacquard bars)
  • Distance between knocking-over bar 0.5-2mm
  • Working width 90"/138"
  • Max. speed 650 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
2396-90" 4100×4500×3400 18.5 8500 8.25
2396-138" 5600×4500×3400 25.2 12500 12.75
