Electric Cargo Van 5.3 Meters
Looking for a cargo van with large space and advanced configurations? This medium-sized electric van has got your back. With a loading volume between 7 to 8.5 cubic meters, a vehicle length of 5,300 meters, and a payload of 1,000kg, this electric cargo van offers you a larger space for cargo delivery. The cargo box of this electric vehicle comes with three dimensions: 1,980mm, 2,080mm, and 2,260mm. Different to other box vans, our electric delivery vans are equipped with a battery heating system that helps maintain optimal battery temperature and thus allows the electric vehicle to perform better in cold weather. In addition to the GB/T fast charging, this electric cargo van also supports 7kW AC fast charging, which shortens the charging process and reduces the time cost. Having taken into account the different traffic regulations in different countries, we offer both left-hand drive and right-hand drive models.
| Main Parameters | Vehicle Dimensions (L*W*H) (mm) | 5,300*1,700*1,980 (M: 2,080 , H: 2,260) |
| Wheel Base (mm) | 2890 | |
| Cargo Box Size (mm) | 3,275*1,565*1,375 (M: 1,465, H: 1,660) | |
| Curb Weight/Total Mass (kg) | 1,760/3,360 | |
| Payload Capacity (kg) | 1,600 | |
| Approach / Departure Angle (°) | 18 / 17 | |
| Front / Rear Suspension (mm) | 685 / 875 | |
| Front / Rear Tracks (mm) | 1,460 / 1,440 | |
| Steering Position | Left Hand Drive | |
| Dynamic Performance | Max. Speed (km/h) | 90 |
| Climbing Capacity (%) | 20 | |
| Battery Capacity (kWh) | CATL-41.86 kWh | |
| Peak Torque (kW/Nm) | 80/300 | |
| Driving Range (km) | 245 | |
| Chassis Steering systems | Drive Mode | Middle-engine Rear-drive |
| Front Suspension | MacPherson Independent Front Suspension | |
| Rear Suspension | Vertical 5 plate spring type | |
| Steering Type | EPS Electronic Power Steering | |
| Wheels Brake System | Tire Size | 195/70 R15LT |
| Wheel Material / Tire | Steel / 4 pcs | |
| Brake Type | Front Disc/ Rear Drum | |
| Parking Brake | Ratcheting Zip Type | |
| Body Structure | Body Structure | Load-supporting |
| NO. of Doors | 4Pcs | |
| NO. of Seats | 2 Seats |
| Remark：● Standard ○ Optional | ||
| Charging Configuration | Fast Charger Compliant with Euro Standards | ● |
| 7 kW AC Fast Charger Compliant with Euro Standards | ○ | |
| Safety Device | Pedestrian Reminder | ● |
| Driver’s Seat Belt Reminder | ● | |
| ABS Anti-lock Braking System | ● | |
| Three-point Safety Belts | ● | |
| Controllability | Reverse Radar | ● |
| Wheel-Slip Control | ● | |
| External Configuration | Latest Design on Front Grille | ○ |
| Front Fog Lamps | ● | |
| Headlamp Height Adjustable | ● | |
| Rear Foot Rest | ● | |
| Central Lock | ● | |
| Remote Control Key | ● | |
| Internal Configuration | Front Door Electric Window | ● |
| Driver and Co-pilot Sunshield | ● | |
| Normal Flooring | ● | |
| Normal Ceiling | ● | |
| Fabric Seat with High Foam Sponge | ● | |
| Enclosed Steel Plate Partition | ● | |
| Multimedia Configuration | Radio USB | ● |
| NO. of Speaker | 2 | |
| AC | Air Conditioner (for cooling) | ● |
| PTC Heater | ● | |
| Safety Equipment | Reflective Vest | ● |
| Warning Triangle | ● | |
-
Equipped with ABS EBD system, increasing the vehicle safety.
-
Optional driving modes of D/S (Drive/Sport) according to road conditions.
-
Adopted with the dual-circuit hydraulic braking system that ensures the vehicle’s stable performance.
-
Equipped with EPS (Electric Power Steering) that provides a better driving experience.
-
Battery heating system allows the vehicle to perform better in cold weather and reduces electricity consumption.
-
GB/T fast charging and 7kW AC fast charging, improving the flexibility of charging.
