Sand Filter, Series CNC-T400
Request a Quote
The top mounted sand filter is designed to remove dust and debris. This is the most popular model due to its low cost.
With proven product quality and performance, we are confident to offer:
- Pool equipment wholesale for distributors
- Everything needed from pool and Spa equipment to pool accessories for pool & Spa contractor
- OEM service for branded suppliers and manufacturers of pool equipment and supplies
- Manufacturing service of pool equipment and supplies for the factories with limited production capacity and product variations.
Technical data
| Model | Tank diameter | Tank height | Flow | Filter area | Connections | Required sand | Package | (NW) | (GW) | |||||||||
| mm | inches | mm | inches | m3/h | GPM | m2 | sq.ft | mm | inches | kg | lbs | mm | inches | kg | lbs | kg | lbs | |
| CNC-T400 | 400 | 15.7 | 680 | 26.8 | 8 | 35 | 0.13 | 1.4 | 50 | 1.5〞 | 35 | 77 | 440*440*480 | 17*17*19 | 7.3 | 16 | 9.8 | 22 |
| CNC-T450 | 450 | 17.7 | 740 | 29.1 | 10 | 44 | 0.16 | 1.6 | 50 | 1.5〞 | 50 | 110 | 470*470*540 | 19*19*21 | 8.8 | 19 | 11.8 | 26 |
| CNC-T500 | 500 | 19.7 | 815 | 32.1 | 11 | 48 | 0.18 | 1.8 | 50 | 1.5〞 | 58 | 128 | 520*520*610 | 21*21*24 | 10.7 | 24 | 14.7 | 32 |
| CNC-T525 | 525 | 20.7 | 865 | 34.1 | 12 | 53 | 0.19 | 1.9 | 50 | 1.5〞 | 65 | 143 | 550*550*630 | 22*22*25 | 11.8 | 26 | 15.8 | 35 |
| CNC-T550 | 550 | 21.7 | 875 | 34.4 | 13 | 57 | 0.2 | 2 | 50 | 1.5〞 | 87 | 192 | 570*570*650 | 22*22*26 | 12.9 | 28 | 17.4 | 38 |
| CNC-T600 | 600 | 23.6 | 885 | 34.8 | 14 | 62 | 0.22 | 2.2 | 50 | 1.5〞 | 115 | 254 | 620*620*660 | 24*24*26 | 14.5 | 32 | 19 | 42 |
| CNC-T625 | 625 | 24.6 | 920 | 36.2 | 16 | 70 | 0.3 | 2.9 | 50 | 1.5〞 | 130 | 287 | 650*650*680 | 26*26*27 | 15.8 | 35 | 21.3 | 47 |
| CNC-T650 | 650 | 25.6 | 950 | 37.4 | 17 | 75 | 0.32 | 3.1 | 50 | 1.5〞 | 145 | 320 | 680*680*725 | 27*27*29 | 17.7 | 39 | 23.2 | 51 |
| CNC-T700 | 700 | 27.6 | 970 | 38.2 | 19 | 84 | 0.35 | 3.4 | 50 | 1.5〞 | 180 | 397 | 720*720*750 | 29*29*30 | 20 | 44 | 25.5 | 56 |
| CNC-T750 | 750 | 29.5 | 1080 | 42.5 | 21 | 92 | 0.4 | 3.9 | 63 | 2〞 | 225 | 496 | 780*780*790 | 31*31*31 | 22.8 | 50 | 29.8 | 66 |
| CNC-T800 | 800 | 31.5 | 1130 | 44.5 | 24 | 106 | 0.5 | 4.9 | 63 | 2〞 | 275 | 606 | 820*820*835 | 32*32*33 | 25.9 | 57 | 33.4 | 74 |
| CNC-T900 | 900 | 35.4 | 1215 | 47.8 | 30 | 132 | 0.64 | 6.3 | 63 | 2〞 | 390 | 860 | 920*920*980 | 36*36*39 | 32.7 | 72 | 42.2 | 93 |
| CNC-T1050 | 1050 | 41.3 | 1380 | 54.3 | 38 | 167 | 0.88 | 8.6 | 63 | 2〞 | 615 | 1356 | 1055*1055*1150 | 42*42*45 | 50.9 | 112 | 56.4 | 124 |
| CNC-T1200 | 1200 | 47.2 | 1515 | 59.6 | 42 | 185 | 1.13 | 11.1 | 63 | 2〞 | 920 | 2029 | 1215*1215*1250 | 48*48*49 | 57.6 | 127 | 63.2 | 139 |
| CNC-T1400 | 1400 | 55.1 | 1720 | 67.7 | 56 | 246 | 1.25 | 12.3 | 63 | 2〞 | 1480 | 3263 | 1415*1415*1450 | 56*56*57 | 69.2 | 153 | 74.7 | 165 |
