The high precision spotting press with two plate clamping is designed and developed based on the JM series die spotting press.

It completes reliable and stable spotting through the use of four evenly distributed spotting oil cylinders, but it has no upper seats, which decreases the machine height by 15-25% when compared to the JM series die spotting press. For users with a limited amount of height in their factory, this is an ideal piece of equipment.

It is equipped with a locking device to guarantee operation security, so that even if there is a power outage or machine breakdown during operation, the brake device will hold the mold plate back and prevent it from continuous movement.

Type selection

According to different pressure capacities, we offer 4 different machine types, ranging from 160T to 600T, including equipment where the minimum mold size is only 22tons, a height of 4m, and a working table length of 1.6m, thus increasing the utilization rate of limited space.

SX160YC-II
  • Pressing capacity: 160 ton
  • Mold open capacity: 38 ton
  • Overturn capacity: 8 ton
  • Ejecting capacity: 6.3 ton
SX300YC-II
  • Pressing capacity: 300 ton
  • Mold open capacity: 56 ton
  • Overturn capacity: 18 ton
  • Ejecting capacity: 6.3 ton
SX400YC-II
  • Pressing capacity: 400 ton
  • Mold open capacity: 80 ton
  • Overturn capacity: 25 ton
  • Ejecting capacity: 11.2 ton
SX600YC-II
  • Pressing capacity: 600 ton
  • Mold open capacity: 150 ton
  • Overturn capacity: 35 ton
  • Ejecting capacity: 21.5 ton
Installation Dimensions
Technical parameter
Items Model   SX160YC-Ⅱ SX300YC-Ⅱ SX400YC-Ⅱ SX600YC-Ⅱ
pressure capacity T 160 300 400 600
Upper workbench lift capacity T 38 56 80 150
Overturn capacity of upper workbench T 8 18 25 35
Ejecting capacity T 6.3 6.3 11.2 21.5
Min mold thickness mm 300 600 600 800
Max mold thickness mm 1000 1600 2000 2800
Maximum distance between two workbenches mm 1700 2300 2700 3500
Overturn angle of upper workbench ° 180 180 180 180
Dimension of workbench mm 1600×1300 2000×1800 3000×2000 4000×2800
Carrying capacity of workbench T 16 36 50 70
Shift-out stroke of lower workbench mm 3200 2750 4800 6800
Ejection stroke mm 300 300 300 350
Power of motor kW 18.5 30 45 55
Min mold size (L×W) mm 460×690 600×750 810×780 2100×1015
External dimension (length×width×high) mm 6500×2790×4370 6010×5145×5850 8300×4480×6460 11250×5590×8500
Overall Dimension (out of operation) mm 6500×2790×3610 6010×5145×4550 8300×4480×5130 8300×4480×5130
Weight T 22 45 80 125

Note: The technical parameters are subject to change without prior notice.

Features
  • Designed with a reliable guide pillar structure, allowing for higher precision during high-pressure mold closure and convenient platen parallelism adjustment.
  • All moving parts are equipped with graphite copper sleeve guides, enabling oil-free and self-lubricating operation for a cleaner and more environmentally friendly machine.
  • Incorporates practical and reliable fault detection, alarm systems, and low-pressure mold protection function for enhanced safety and performance.
  • Equipped with a lower worktable featuring high-precision positioning and lifting devices, further improving operational efficiency.
  • Features four mold clamping cylinders, ensuring even force distribution during high-pressure mold closure and minimizing deformation coefficient.
  • Utilizes German-made SIKO magnetic band for precise detection of the moving platen's position, guaranteeing accurate results.
  • The reduced machine height by 15-25% compared to the JM series solves the issue of limited factory height, providing optimal space utilization.
Optional device
Servo drive system

Serve driving using an optional servo motor can help reduce the die spotting press' oil temperature and energy consumption.

Magnetic mold plate

Magnetic mold plates can be used in conjunction with the die spotting press in order to achieve a reliable and fast die change.

Hydraulic clamping system

We offer a variety of hydraulic clamping systems that match the die spotting press, thus helping customers achieve a fast, reliable die change.
