Die Spotting Press, JM High Precision Series
The design fundamentals of the JM high precision series die spotting press are similar to the YC series, in that it is also equipped with four reliable guide pillars, an elastic mold plate and four spotting oil cylinders, ensuring the mold plate force is uniform and the spotting precision is high.
The main difference between the JM and YC series lies in the overall arrangement. It is important to utilize space effectively inside the plant, and in order to assist customers in doing so, we designed the JM series as a right angle types, and the YC series as a linear type. In doing so, users can choose which machine best fits their factory layout.
According to different pressure capacities, we offer 10 different machine types, with a size varying from 80T to 600T. The mix mold size they can process is 3.5m×2.5m.
- Pressing capacity: 80 ton
- Mold open capacity: 22 ton
- Overturn capacity: 2.5 ton
- Ejecting capacity: 2.2 ton
- Pressing capacity: 120 ton
- Mold open capacity: 25 ton
- Overturn capacity: 4 ton
- Ejecting capacity: 2.2 ton
- Pressing capacity: 160 ton
- Mold open capacity: 38 ton
- Overturn capacity: 8 ton
- Ejecting capacity: 6.3 ton
- Pressing capacity: 200 ton
- Mold open capacity: 45 ton
- Overturn capacity: 10 ton
- Ejecting capacity: 6.3 ton
- Pressing capacity: 260 ton
- Mold open capacity: 50 ton
- Overturn capacity: 10 ton
- Ejecting capacity: 6.3 ton
- Pressing capacity: 300 ton
- Mold open capacity: 56 ton
- Overturn capacity: 18 ton
- Ejecting capacity: 6.3 ton
- Pressing capacity: 350 ton
- Mold open capacity: 70 ton
- Overturn capacity: 25 ton
- Ejecting capacity: 11.2 ton
- Pressing capacity: 400 ton
- Mold open capacity: 80 ton
- Overturn capacity: 25 ton
- Ejecting capacity: 11.2 ton
- Pressing capacity: 500 ton
- Mold open capacity: 120 ton
- Overturn capacity: 30 ton
- Ejecting capacity: 21.5 ton
- Pressing capacity: 600 ton
- Mold open capacity: 150 ton
- Overturn capacity: 35 ton
- Ejecting capacity: 21.5 ton
Items Model | SX80JM | SX120JM | SX160JM | SX200JM | SX260JM | SX300JM | SX350JM | SX400JM | SX500JM | SX600JM |
A | 1000 | 1400 | 1600 | 1800 | 2000 | 2200 | 2800 | 3000 | 3100 | 3500 |
B | 800 | 1100 | 1300 | 1500 | 1600 | 1800 | 2000 | 2000 | 2100 | 2500 |
C | 1305 | 1700 | 1920 | 2120 | 2220 | 2635 | 3230 | 3440 | 3535 | 4135 |
D | 1530 | 2085 | 2360 | 2560 | 2760 | 3210 | 3810 | 4050 | 4280 | 4690 |
E | 765 | 765 | 765 | 765 | 765 | 715 | 715 | 715 | 715 | 715 |
F | 3600 | 4550 | 5045 | 5445 | 5745 | 6560 | 7755 | 8205 | 8530 | 9540 |
G | 1240 | 1680 | 2000 | 2200 | 2300 | 2680 | 2880 | 2960 | 3200 | 3560 |
H | 960 | 1430 | 1480 | 1680 | 1780 | 1990 | 2250 | 2210 | 2240 | 2840 |
I | 2820 | 3740 | 3910 | 4310 | 4510 | 5280 | 5740 | 5470 | 5740 | 6700 |
J | 22 | 22 | 28 | 28 | 28 | 36 | 36 | 36 | 36 | 36 |
K | 537 | 682 | 762 | 832 | 832 | 905 | 975 | 1025 | 1125 | 1250 |
L | 746 | 970 | 1040 | 1135 | 1135 | 1225 | 1515 | 1565 | 1665 | 1880 |
M | 495 | 698 | 800 | 900 | 950 | 1115 | 1410 | 1475 | 1565 | 1790 |
N | 445 | 670 | 640 | 750 | 850 | 910 | 1030 | 990 | 990 | 1350 |
O | 940 | 1280 | 1500 | 1700 | 1800 | 2060 | 2260 | 2260 | 2400 | 2800 |
P | 1120 | 1645 | 1860 | 2060 | 2260 | 2550 | 3150 | 3350 | 3470 | 3900 |
Q | 3655 | 4580 | 5190 | 5680 | 5765 | 6780 | 7140 | 7340 | 8470 | 9275 |
R | 150 | 200 | 200 | 200 | 200 | 200 | 400 | 400 | 400 | 400 |
S | 1120 | 1500 | 1700 | 1900 | 1900 | 2300 | 2500 | 2500 | 3000 | 3200 |
T | 1000 | 1300 | 1500 | 1700 | 1700 | 2100 | 2100 | 2100 | 2600 | 2800 |
HA | 550 | 600 | 750 | 800 | 800 | 900 | 900 | 950 | 1050 | 1100 |
LA | 800 | 800 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 |
LB | 800 | 800 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 |
WA | 800 | 800 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 |
WB | 800 | 800 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 |
- Designed with reliable guide pillar, enabling high precision during high-pressure mold closure and convenient platen parallelism adjustment.
- All moving parts are equipped with graphite copper sleeve guides, ensuring oil-free and self-lubricating operation for a cleaner and more environmentally friendly machine.
- Incorporates practical and reliable fault detection, alarm systems, and low-pressure mold protection function for enhanced safety and performance.
- Equipped with a lower worktable featuring high-precision positioning and lifting devices, further improving operational efficiency.
- Features four mold clamping cylinders, ensuring even force distribution during high-pressure mold closure and minimizing deformation coefficient.
- Utilizes German-made SIKO magnetic band for precise detection of the moving platen's position, guaranteeing accurate results.
- Includes mechanical safety protection devices to safeguard both your valuable molds and the machine itself.
During the spotting process, operators need to simply place two molds on the rolling bolster and upper platen, respectively. When the molds are fixed in place using a hydraulic clamping system, the equipment will begin to operate. The rolling bolster moves forward, while at the same time, the upper platen moves upwards and reverses to 180 degrees. By doing so, the two piece mold will effectively complete spotting in their positions.
Four guide pillars ensure the entire unit is stable and reliable, and the parallel position of the mold can be adjusted simply by shifting the guide pillar nut positions, thus ensuring a high spotting precision. We also use an elastic mold plate to guarantee the high spotting precision under a high pressure.
Once the rolling bolster returns to its original position, our hydraulic machinery safety will attach and lock it automatically, which makes mold and machinery operation safer and more secure.
Serve driving using an optional servo motor can help reduce the die spotting press' oil temperature and energy consumption.
Magnetic mold plates can be used in conjunction with the die spotting press in order to achieve a reliable and fast die change.
We offer a variety of hydraulic clamping systems that match the die spotting press, thus helping customers achieve a fast, reliable die change.
