Die Cutting and Stripping Machine, ZBQF Series
ZBQF series die cutting and stripping machine is typically designed for manufacturing paper cups. It consists of two sections, i.e. die cutting unit and stripping unit.
The die cutting unit is offered in various configurations adapted to customers’ specific needs. And the stripping unit is connected to the die cutting machine for blank separation while sending the wastes into waste basket.
Model | ZBQF970x550(640) | ZBQF1080x640 |
Max. cutting area | 950mm×520mm (610mm) | 1050mm×610mm |
Cutting precision | 0.20mm | 0.20mm |
Paper weight | 120-400g/㎡ | 120-400g/㎡ |
Machine speed | 100-180 times/min | 100-180 times/min |
Air pressure | 0.6Mpa | 0.6Mpa |
Air consumption | 0.25m³/min | 0.25m³/min |
Max. cutting pressure | 150 T / 280 T | 280 T |
Max. web roll diameter | 1600mm | 1600mm |
Power | 20kW | 22kW |
Stripping precision | 99% | 99% |
Pile height | 18-25mm | 18-25mm |
Paper width | Max. 950mm Min. 500mm | Max. 1050mm Min. 500mm |
Machine weight | 8T | 10T |
Machine dimensions | 8000×2500×2000mm | 10000×2500×2000mm |
Model: ZBQF970x550
Max. paper width: 950mm×520mm
Cutting precision: 0.20mm
Paper weight: 120-400g/㎡
Machine speed: 100-180 times/min
Air pressure: 0.6Mpa
Air consumption: 0.25m³/min
Max. cutting pressure: 150T
Max. web roll diameter: 1600mm
Power: 20kW
Stripping precision:99%
Pile height:18-25mm
Paper width:Max. 950mm Min. 500mm
Machine weight:8T
Machine dimensions:8000×2500×2000mm
Model: ZBQF970x640
Max. paper width: 950mm×610mm
Cutting precision: 0.20mm
Paper weight: 120-400g/㎡
Machine speed: 100-180 times/min
Air pressure: 0.6Mpa
Air consumption: 0.25m³/min
Max. cutting pressure: 280 T
Max. web roll diameter: 1600mm
Power: 20kW
Stripping precision:99%
Pile height:18-25mm
Paper width:Max. 950mm Min. 500mm
Machine weight:8T
Machine dimensions:8000×2500×2000mm
Model: ZBQF1080x640
Max. paper width: 1050mm×610mm
Cutting precision: 0.20mm
Paper weight: 120-400g/㎡
Machine speed: 100-180 times/min
Air pressure: 0.6Mpa
Air consumption: 0.25m³/min
Max. cutting pressure: 280 T
Max. web roll diameter: 1600mm
Power: 22kW
Stripping precision:99%
Pile height:18-25mm
Paper width:Max. 950mm Min. 500mm
Machine weight:8T
Machine dimensions:10000×2500×2000mm
