Automatic Two-Sided Terminal Crimping Machine Manufacturer

Automatic Two-Sided Terminal Crimping Machine

Request a Quote

View All: http://wirecrimping-en.com/1-4-general-purpose-wire-crimping.html

Our general-purpose wire crimping equipment supports a variety of wire processing functions, including cutting, double-sided and single-sided crimping, double-sided and single-sided stripping, as well as combining crimping on one end with stripping on the other. Its versatile capabilities make it ideal for diverse wire harness production needs, providing consistent and precise results.

Crimping Capacity

3,500 wires per hour at 100mm length

Technical Data

General	Model
	Dimensions (L×W×H)	650×750×1500mm
	Weight	Approx. 450kg
	Power Supply	AC220V 50Hz
	Rated Current	10A
	Power	2.8kW
	Air Pressure	0.4-0.6Mpa (the air must be filtered and dried)
	Space Requirement	1×1m
	Crimping Force	2T
Functions	Crimping Capacity	3500 wires/hr at 100mm length (depending on the wire length)
	Wire Processing	Wire cutting, One-sided stripping, Two-sided stripping, One-sided crimping, Two-sided crimping, One-sided crimping one-sided stripping
	Control System	LCD display, single-chip microcontroller
	Detection Devices	Crimp test, wire shortage detection, air pressure test, paper winding inspection
	Auxiliary Equipment	Crimp terminal waste / wire strip waste collector, paper winder, air storage buffer tank
	Operation Control	Wire feeding, cutting, stripping and movement are controlled via touch screen
Optional	Pressure Measuring Device	Used to measure terminal crimping pressure
Application Range	Cutting Length	40-9999mm
	Stripping Length	Front: 1-10mm, Rear: 1-10mm
	Wire & Cable Type	Electric wire, high temperature cable, Teflon insulated cable (AWG24#-AWG18#)

Features

Controlled via a Chinese LCD microcontroller, enabling quick and efficient setup and adjustments.
Integrated with a real-time error monitoring system that displays alerts on a touch screen, simplifying troubleshooting and ensuring minimal downtime.
