Glass Microfiber Vacuum Insulation Panel (VIP)
To provide extraordinary thermal conductivity and low rebound performance, the Glass Microfiber VIP blends a hot-pressed glass microfiber core with alkali-free fiberglass film. This VIP is perfect for uses where high-performance thermal protection is needed since it has a rebound rate of less than 10% and thermal conductivity < 0.004 W/m·K, so offering exceptional insulation efficiency.
Ideal for both commercial and industrial applications, this VIP is built to provide long-lasting stability and energy-saving insulation with its sophisticated design.
Features
- Uses alkali-free fiberglass film, with hot pressed glass microfiber core material.
- Low rebound rate expansion coefficient less than 10% for long-term stability.
- Better thermal conductivity, lower then 0.004 W/m·K
Comparison of Specifications
| Core Material | Fiberglass | Maximum Size (mm) | 700×1200 |
| Film | Barrier Film | Thickness (mm) | 6 to 30 |
| Color | White | Density (kg/m³) | 300 to 350 |
| Temperature Range (℃) | -80 to 85 | Length And Width Tolerance (mm) | ±5 |
| Structure | Rectangular | Thickness Tolerance (mm) | ±3 |
| Standard Size | Customized Size | Thermal Conductivity (W/m·K) | < 0.005 |
Need Assistance?
Have questions or want more information? Our team is here and ready to help you.
Application Examples
Electric vehicle batteryEnergy storage and insulationAerospace engineeringRelated products
