S Series High Power Laser Cutter
Fiber Laser Cutting Machine, Fiber Laser Cutting System
The S series high power laser cutter is designed to cut thick metal sheets, and features a power range of 4000W to 15000W. The maximum thickness of stainless steel sheets to be cut is 50mm, while the maximum thickness of aluminum sheets is 60mm, and brass sheets is 25mm.
The guide rails, racks and pinions, servo motors and gear reducers of the high power laser cutter are all imported from international well-known brands, so the safety and stability during high power operation is guaranteed.
The full glass cover will protect operators against laser radiation, ensuring this laser performs efficient and environmentally friendly cutting.
The tensile strength of the cast iron machine bed exceeds 200Mpa. After quenching and tempering, the cast iron machine bed is exceptionally strong and tough, ensuring the equipment remains stable, even when cutting at a high power.
Because of the Precitec’s auto focus laser heads, the laser machine can cut faster and more accurately. Besides, the laser heads can automatically change the nozzles according to the thickness and the material of the metal sheets to improve the working efficiency.
- Aerospace
- Shipbuilding
- Auto parts
- Heavy industrial equipment
- Boiler
- Elevator
- Medical equipment
- Stainless steel
- Alloy steel
- Carbon steel
- Aluminum alloy
- Galvanized steel
- Copper
- Titanium
| Model | S3015 | S4020 | S6020 | S6025 | S8025 |
| Working Area | 3100*1550mm | 4070 * 2040mm | 6100 * 2040mm | 6100 * 2540mm | 8100 * 2540mm |
| Laser output power | 15000w/12000w/10000w/8000w/6000w/4000w | ||||
| X/Y-axis positioning accuracy | 0.05mm | ||||
| X/Y-axis repositioning accuracy | 0.03mm | ||||
| X/Y-axis max. speed | 200m/min | ||||
- IPG high power fiber laser
- SMC electric proportional valve
- Beckhoff servo motor
- Atlanta high precision rack and pinion
- Neugart gear reducers
- Rexroth high precision guide
