Our diesel generator sets are equipped with high-performance diesel engines from Weichai Group, designed to perform reliably in extreme conditions such as high-temperature, high-humidity, and high-altitude environments. Meeting China Stage III and above emission standards and certified under the ISO 9001 quality management system, these generator sets deliver steady output and consistent performance. Widely used across telecommunications, healthcare, oil and gas, rail transport, agriculture, and emergency response, they combine Weichai’s proven engine technology with strong power output to provide efficient and durable electricity solutions for diverse applications.

Frequency	50Hz
Prime Power	20-2500kVA (16-2000kW)
Standby Power	23-2750kVA (18-2200kW)
Fuel Consumption	6.2-556.2L/h
Displacement	2.3-65.7L

Technical Specifications

50Hz Diesel Generator Sets

Genset Model	Prime Power		Standby Power		Engine Model	Fuel Consumption	Cylinder	Displacement
Genset Model	kVA	kW	kVA	kW	Engine Model	L/h	Cylinder	L
CDW23	20	16	23	18	WP2.3D25E200	6.2	4L	2.3
CDW33	30	24	33	26	WP2.3D33E200	7.6	4L	2.3
CDW41	38	30	41	33	WP2.3D40E200	9.3	4L	2.3
CDW50	45	36	50	40	WP2.3D48E200	10.7	4L	2.3
CDW69	63	50	69	55	WP4,1D66E200	15.2	4L	4.1
CDW88	80	64	88	70	WP4.1D80E200	18.4	4L	4.1
CDW110	100	80	110	88	WP4.1D100E200	21.4	4L	4.1
CDW150	125	100	150	120	WP6D132E200	30.1	6L	6.8
CDW165	150	120	165	132	WP6D152E200	32.9	6L	6.8
CDW188	170	136	188	150	WP6D167E200	35.6	6L	6.8
CDW220	200	160	220	176	WP10D200E200	42.3	6L	9.7
CDW250	230	184	250	200	WP1OD238E200	51.2	6L	9.7
CDW275	250	200	275	220	WP10D264E200	57.3	6L	9.7
CDW359	313	250	350	280	WP10D320E200	70.9	6L	9.7
CDW375	313	250	375	300	WP12D353E200	75	6L	11.6
CDW400	375	300	400	320	WP13D385E200	82.6	6L	12.5
CDW500	438	350	500	400	WP13D440E310	104	6L	12.5
CDW550	500	400	550	440	WP13D490E310	110.1	6L	12.5
CDW650	575	460	650	520	6M33D572E200	123.5	6L	19.6
CDW725	650	520	725	580	6M33D633E200	137.1	6L	19.6
CDW750	675	540	750	600	6M33D670E200	150.2	6L	19.6
CDW825	750	600	825	660	6M33D725E310	155.3	6L	19.6
CDW875	800	640	875	700	12M26D792E200	173.5	12V	31.8
CDW900	800	640	900	720	8M33D800E200	154.8	8V	26.1
CDW1000	900	720	1000	800	8M33D890E200	188.5	8V	26.1
CDW1000	900	720	1000	800	12M26D902E200	198	12V	31.8
CDW1100	1000	800	1100	880	8M33D975E310	177.2	8V	26.1
CDW1100	1000	800	1100	880	12M26D968E200	206.5	12V	31.8
CDW1250	1125	900	1250	1000	12M33D1108E200	237.6	12V	39.2
CDW1375	1250	1000	1375	1100	12M33D1210E200	260.6	12V	39.2
CDW1500	1375	1100	1500	1200	12M33D1320E200	279.9	12V	39.2
CDW1650	1500	1200	1650	1320	12M33D1500E310	314.8	12V	39.2
CDW1750	1563	1250	1750	1400	16M33D1530E310	330.6	16V	52.3
CDW1900	1750	1400	1900	1520	16M33D1680E310	367.2	16V	52.3
CDW2063	1875	1500	2063	1650	16M33D1800E310	430.4	16V	52.3
CDW2250	2000	1600	2250	1800	16M33D1980E310	426.8	16V	52.3
CDW2250-1	2000	1600	2250	1800	20M33D2020E310	477.5	20V	65.4
CDW2500	2250	1800	2500	2000	20M33D2210E310	477.5	20V	65.4
CDW2500-1	2250	1800	2500	2000	12M55D2210E310	556.2	12V	65.7
CDW2750	2500	2000	2750	2200	12M55D2450E310	556.2	12V	65.7
